Sell 12v0.5a Switching AC-DC Adapters (US plug)

Model:GFP051U-1205B
Brand:MOUNT
Origin:Made In China
Category:Electronics & Electricity / Power Supply & Distribution / Switching Power Supply
Label:12v , 12v500ma , 5v adaptor
Price: US $2.5 / pc
Min. Order:500 pc
Inquire Now Add to Basket

Member Information

Detail

Shenzhen GEAO Technology Co.,ltd

Biz MemberGuang Dong - China
Live Chat:
点击这里给我发消息Last Online:30 Mar, 2020

Product Description

GFP051U-0315B [3V1.5A]
GFP051U-A315B [3.3V1.5A]
GFP051U-4207B [4.2V0.7]
GFP051U-4212B [4.2V1.2A]
GFP051U-4505B [4.5V0.5A]
GFP051U-4510B [4.5V1A]
GFP051U-0505B [5V0.5A]
GFP051U-0510B [5V1A]
GFP051U-0610B [6V1A]
GFP051U-7508B [7.5V0.8A]
GFP051U-0965B [9V0.65A]
GFP051U-1205B [12V0.5A]
GFP051U-1504B [15V0.4A]
GFP051U-2425B [24V0.25A]


Model Number

Input Range

Output Range

GFP051U-0315B























90-240V

3.0V

1.5A

GFP051U-A315B

3.3V

1.5A

GFP051U-4207B

4.2V

0.7A

GFP051U-4212B

4.2V

1.2A

GFP051U-4505B

4.5V

0.5A

GFP051U-4510B

4.5V

1.0A

GFP051U-0505B

5.0V

0.5A

GFP051U-0510B

5.0V

1A

GFP051U-0610B

6.0V

1A

GFP051A-7508B

7.5V

0.8A

GFP051U-0965B

9.0V

0.65A

GFP051U-1205B

12V

0.5A

GFP051U-1504B

15V

0.4A

GFP051U-2425B

24V

0.25A

DIMENTION:L×W×H=45.5×33×23.4

[Input Voltage]: AC 100-240V,50/60Hz
[Range Voltage]: AC 90--264V,47/63Hz
[Output Power]: 5W
[Output Voltage]: 3V-24V
[Over Voltage Protection]: 120%min
[Over Current Protection]: 120%min
[Short Protection]: Auto Recovery
[Load Regulation]: ±5%
[General Specifications]:
[Operating Temperature]: 0~40℃
[Storage Temperature]: -20~85℃
[Operating Relative Humidity]: 5~95%RH
[Withstanding Voltage]: AC 3000V(Min),5mA(Max)
[Insulation Resistance]: DC 500V 100MΩ(Min)
[Safety]: UL/cUL PSE CCC CE  FCC BSMI  CEC

[Market]:Japan,USA,Canada,China,Taiwan


G051U-030120B-1 [3V@1.2A]
G051U-033120B-1 [3.3V@1.2A]
G051U-042070B-1 [4.2V@0.7]
G051U-042120B-1 [4.2V@1.2A]
G051U-045050B-1 [4.5V@0.5A]
G051U-045100B-1 [4.5V@1A]
G051U-050050B-1 [5V@0.5A]
G051U-050100B-1 [5V@1A]
G051U-060050B-1 [6V@0.5A]
G051U-060100B-1 [6V@1A]
G051U-075080B-1 [7.5V@0.8A]
G051U-090065B-1 [9V@0.65A]
G051U-120050B-1 [12V@0.5A]
G051U-150040B-1 [15V@0.4A]
G051U-240020B-1 [24V@0.25A]

If you need our product,

Pls send email to zenger@mountpower.net.cn,

We will offer the best price according the Qty,and we can ship goods to all over the world.

We can accept paypal payment.


Payment Terms:TT/LC
