| Model: | GEO151DA-120150 |
|---|---|
| Brand: | GEO |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Power Supply & Distribution / Power Adaptor |
| Label: | 12V1.5A AC ADAPTER , GEO151DA-1215 , 12VDC power adaptor |
| Price: |
US $4.5
/ pc
|
| Min. Order: | 500 pc |
| Live Chat: |  | Last Online:09 May, 2024 |
GEO151DA-0330 [3V3A]
GEO151DA-A0330 [3.3V3A]
GEO151DA-0530 [5V3A]
GEO151DA-0628 [6V2.8A]
GEO151DA-0920 [9V2A]
GEO151DA-1018 [10V1.8A]
GEO151DA-1215 [12V1.5A]
GEO151DA-1512 [15V1.2A]
GEO151DA-2407 [24V0.75A]
|
Model Number |
Input Range |
Output Range |
|
|
GEO151DA-0330 |
90-240V |
3.0V |
3.0A |
|
GEO151DA-A330 |
3.3V |
3.0A |
|
|
GEO151DAA-0530 |
5.0V |
3A |
|
|
GEO151DA-0628 |
6.0V |
2.8A |
|
|
GEO151DA-0920 |
9.0V |
2A |
|
|
GEO151DA-1018 |
10V |
1.8A |
|
|
GEO151DA-1215 |
12V |
1.5A |
|
|
GEO151DA-1512 |
15V |
1.2A |
|
|
GEO151DADA-2407 |
24V |
0.75A |
|
DIMENTION:L*W*H=68.5*50*26.5
[Input Voltage]: AC 100-240V,50/60Hz
[Range Voltage]: AC 90--264V,47/63Hz
[Output Power]: 18W
[Output Voltage]: 3V-24V
[Over Voltage Protection]: 120%min
[Over Current Protection]: 120%min
[Short Protection]: Auto Recovery
[Load Regulation]: ±5%
[Operating Temperature]: 0~40℃
[Storage Temperature]: -20~85℃
[Operating Relative Humidity]: 5~95%RH
[Withstanding Voltage]: AC 3000V(Min),5mA(Max)
[Insulation Resistance]: DC 500V 100MΩ(Min)
[Safety]: UL/cUL PSE GS/TUV BS CE CB FCC SAA C-Tick EK CCC BSMI
[Market]:Japan,USA,Europe,England,Australia,China,Taiwan,Korea
| Payment Terms: | T/T,PAYPAL |
|---|---|
