Mirror Lcd Advertising Player
Product Description
This pattern has a 15 inch 17 inch 19 inch 22 inch 26 inches make to order, color have champagne gold, silver, black customization
Summary:
☆1080P HD LCD advertising player use the newest MST6M48 HD multi media decode strategy.The strategy via the incorporated design,it no only improves the screen drive and LCD ad player have a high integration,reduces the signal decay,makes the picture smoothy,it is more conveniencet to install,maintain and use. ☆The 1080P HD LCD advertising player uses the TFT LCD PANLE and the HP master chip MST6M48,the master chip is including 3D COMB FILTER and 3D DEINTERLACE,it is better to test different input signal.It is including the powerful audio process and output the high quality picture and tone. ☆Two USB 2.0 interface,support display the pictures、music、video and so on.,support input within 1080P(it is including 480P、720P、1080P),Support WUXGA(Wide screen super spread the pictures display)(1920X0180 @60HZ)HD input Signal,Output effect will be better and offer the HD video, have the powerful audio at the same time.And it can supply the output 2X6W,energy-saving and low power,Standby power below 1W.
Specifications:
Support Format |
Video Format |
MPG\MPG-1\MPG-2\MPG-4\AVI\MP\TS\DIV\TRP\MKV\WMV\RM\RMVB |
Picture Format |
JPG\BMP |
Audio Format |
MP3\WMA |
Support Video decode |
MaximumResolution |
1920*1080/1920*1200 |
MaximumColor Depth |
24bit |
Maximum frame rate |
30frm/s |
Maximum Streaming |
USB 2.0 device:30Mb/s |
Audio Decoding Support |
Sampling rate |
32kHz\44.1kHz\48kHz\96kHz |
Bit rate |
32kbps-- 384kbps |
Other Parameters |
Power Supply |
DC12V/300mA |
Power consumption |
﹤3W |
Frequency response |
±3dB(20Hz—20KHz |
Crosstalk |
75dB |
Audio output |
47K Uefa impedance |
Video output |
CVBS 75 Uefa impedance |
USB transfer rate |
USB 2.0 Max 480Mbpx |
Product Function: • Support horizontal screen/vertical screen broadcasting; • Boot automatically looping; • Support power memory play function; • Support inter cutvideo advertisement function; • Support timer Power On/Off function; • Support Large hanging angle BMP icon display (similar to the TV logo play function); • Support ultra-long scrolling marquee display; • Support function of copy/delete directly on the player; • Support function of update by USB; • Auto records of display, no need any action; • Support full screen/split screen( split screen is for option); • Time-sharing volume; • Max resolution is 1080P(1920*1080), 1080I(1920*1080); • Support display with USB, breaks function; • Audio format supported: MPG\MPG-1\MPG-2\MPG-4\AVI\MP4\DIV\TS\TRP\MKV\WMV\RM\RMVB\JPG\BMP; • Display mode: singles loop, files loop, over-all loop; • Image mode: swirling, zooming, shifting, PPT, background music; • Audio mode: Left/Right/stereo channel; • OSD multi-language: Chinese, English and so on; • Support Chinese and English rolling caption; • Perpetual calendar; • High lightness and definition (manually adjust of lightness, contrast,color temperature and so on; • Software update and upgrade by USB.
Network solutions (optional)
Touch scheme (optional)
Product Image
Img 1
