| Model: | EPGC201/EPGC202 |
|---|---|
| Brand: | NOVA |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Insulation Material |
| Label: | Epoxy Glass Laminate , Fiberglass Materials , G10 laminate sheets |
| Price: |
US $5.5
/ kg
|
| Min. Order: | 500 kg |
| Live Chat: | Last Online:16 May, 2019 |
Epoxy Glass Fabric Laminated sheets
(NEMA Grade: G11; IEC Grade: EPGC203; DIN 7735 Grade:HGW2372.2)
Descriptions:This grade is similar to G10, with the addition of a higher operating temperature,and improved mechanical strength at elevated temperature up to 180 degree celsius.Temperature index: 155C / 180C
Advantages:Except for standard G11, we also have high performance G11 for your extremely strict demand. It has proof tracking index 600V, halogen-free, and flame retardant, H class heat-resistant, widely used in harsh conditions(high humidity, dusty, filthy).
|
Item |
Epoxy Glass Fabric Laminated Sheets (Epgc201/Epgc202/Epgc203/Epgc204) |
|
H.S code |
39219090 |
|
Grade |
G10/FR4 |
|
Material |
Fiberglass |
|
Sheet Size |
915mm*1220mm, 1020mm*1220mm, 1020mm*2040mm, 1220mm*2440mm |
|
Thickness Range |
0.1mm-200mm |
|
Base color |
Natural Green, Yellow, Black |
|
Temperature Classification |
B 130 |
|
Maximum Voltage |
20KV-100KV |
|
International Norms |
ROHS, SGS |
|
Packaging Details |
500-1000kgs Per Pallet or as Required |
|
Lead Time |
7-15 Days After Confirmed |
|
Payment |
L/C, T/T, Western Union, paypal |
|
Shipping |
By Sea, By Air, By Express |
