| Model: | SHMB3515E |
|---|---|
| Brand: | SHOOT |
| Origin: | Made In China |
| Category: | Industrial Supplies / Tools / Woodworking |
| Label: | woodworking machine , finger jointing line , auto finger jointing |
| Price: |
US $24000
/ pic
|
| Min. Order: | 1 pic |
| Live Chat: | Last Online:09 Apr, 2024 |
| Auto Finger Jointing Shaper Line | |
| Feature | |
|
The line including 2pcs machine and other accessories working feed table. (1# and 2#), #2 finger jointing with gluing function |
|
| Model | SHMB3515E |
| Maximum Processing Width | 610mm |
| Maximum Processing Thickness | 160mm |
| Maximum Processing Length | 800mm |
| Main Shaft Speed | 6300r/min |
| Scoring Saw Blade Motor Speed | 2900r/min |
| Saw Blade Speed | 2900r/min |
| Jointing Cutter Diameter | 160mm |
| Spindle Diameter | 50mm |
| Spindle Motor Power | 15kw*2 |
| Saw Blade Motor Power | 4kw*2 |
| Conveyor Belt Motor Power | 0.55kw*2 |
| Servo Motor Power | 0.75kw*2 |
| Air Consumption | 0.6-0.8Mpa |
| Overall Dimensions | 2400x1600x1500mm 2800x1600x1500mm |
| Total Power | 43kw |
| it have one set (21pcs) cutter and one set (7pcs) circular saw with machine | |
| Look Machine Video,click the Youtube website: | |
| https://youtu.be/U5RQlwU30EU | |
