Gravure Printing Machine (double, double take)

Model:GTSAY-****B
Brand:guotong
Origin:Made In China
Category:Industrial Supplies / Plate Making & Printing Machine
Label:printing machine , computer , machine
Price: -
Min. Order:6 pc
Inquire Now Add to Basket

Company Information

Detail

Product Description

Gravure Printing Machine (double, double take) (GTSAY-****B Type) Use: This machine applicable to BOPP, PET, PVC, PE, CPP, has an excellent Web properties, such as drum-shaped multi-color printed materials.   Features: The machine is modular, user requirements may change color printing group; can be both positive and negative for the completion of the first printing. 360 degrees Barebone sets, convenient and reliable operation. Transmission gear box parts of the structure, all sealed lubrication oil. Release volume and put volume using magnetic clutch controller traction, rolling torque motor used (4). Design of dual-drying, dry fast, fast printing speed. Admission, release volumes are duplex digital agencies, two sets of main motor.   Advantages:A machine can be used when the two, both before and after the bit flip duplex structure   Main technical parameters:
Type GTSAY-600B GTSAY -800B GTSAY -1000B GTSAY -1200B
Plate diameter 100-300mm (Special specifications can be customized)
Maximum printing width 600mm 800mm 1000mm 1200mm
Retractable roll diameter 500mm 500mm 500mm 500mm
Printing speed 5-60m/min 5-60m/min 5-60m/min 5-60m/min
Overprint precision ≤0.15mm ≤0.15mm ≤0.15mm ≤0.15mm
Drying methods Electric heating Electric heating Electric heating Electric heating
Machine power 32kw 34kw 36kw 40kw
Machine Weight 5600KG 6000KG 6500KG 7000KG
Machine size 7800*1800*2300mm 7800*2000*2300mm 7800*2200*2300mm 7800*2400*2300mm

Product Image

Gravure Printing Machine (double, double take) 1
Img 1
Gravure Printing Machine (double, double take) 2
Img 2
Gravure Printing Machine (double, double take) 3
Img 3
Gravure Printing Machine (double, double take) 4
Img 4
