| Model: | LS500 |
|---|---|
| Brand: | MYD |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | filter bag , filter , filter cloth |
| Price: |
US $12.3
/ gsm
|
| Min. Order: | 1000 gsm |
| Live Chat: | Last Online:15 Mar, 2021 |
|
Product Code
|
LS500
|
|
Component
|
Needle filtration felt: 100% PPS (Ryton)
Scrim: 100% PPS (Ryton)
|
|
Weight (g/㎡)
|
500±25
|
|
Thickness (mm)
|
2.0±0.2
|
|
Breaking strength
|
Warp ≥ 700N Weft ≥ 1000N
|
|
Elongation (%)
|
Warp ≤ 35 Weft ≤ 55
|
|
Air permeability (L/㎡.S)
|
150 ~ 250
|
|
Operating temperature
|
Continuous : 190℃ Instant: 210℃
|
|
Surface finished
|
Heat set, singed, calendered, membrane, Oil & water repellent, PTFE, etc.
|
