GONSIN TC-RF04
DSSS Wireless Interpretation System



GONSIN TC-RF04 DSSS wireless interpretation system utilizes worldwide license-free 2.4GHz frequency band and state-of-the-art Direct Sequence Spread Spectrum (DSSS) technology to deliver CD quality sound, provide excellent immunity from both noise and interference, and insure high security against unauthorized listening.

The system offers distortion-free wireless solution for simultaneous interpretation and audio distribution in up to 8 channels, with working range of 50 to 200 meters, ideally suited for use in business and government conferences, international conventions and other multilingual applications.


DSSS Control Unit  TC-RFZ04
The microprocessor based TC-RFZ04 control unit is able to transmit 4 audio channels, featuring independent channel level control, independent channel level indicators, and independent channel outputs for sound recording. Via a dB25 cable, multiple interpreter consoles can be connected to the control unit in a daisy-chain. Multiple control units can be cascaded together to form a system for 16 audio channels.


DSSS  Antenna Unit  TC-RFF02
TC-RFF02 antenna unit, designed for 2 channels, is suitable for both indoor and outdoor use. Equipped with channel selection and channel locking function, the unit is powered by the control unit via a coaxial feed cable. The antenna unit can be mounted on wall or tripod stand.


DSSS Receiver  TC-RFJ04F
The TC-RFJ04F receiver is available with 4 audio channels, and each channel utilizes DSSS with a unique spreading code, offering CD-quality sound. The unit is powered by a rechargeable Lithium-ion battery pack. The selected channel number, battery level and RF signal strength are shown on LCD screen. Equipped with individual wireless RF receivers, participants can listen to any selected language channel on a personal earphone, monitor the battery status, check whether or not the unit is receiving the signal properly, and adjust volume level for comfortable listening. Any number of receivers can be used within the effective working range.



Stereo Headphone  TC-D3
Frequency response: 20 Hz - 20 KHz
Impedance: 32 ohms
Sensitivity: 115dB SPL/1mW
Adjustable headband & swivel earcups
30mm drivers for dynamic stereo sound
120cm single entry cord with 3.5mm plug
