Metal Bench Lathe Machine CZ1340V CZ1440V CZ1237V
Product Description
| Metal Bench Lathe Machine |
| Model |
CZ1340V |
| Swing over bed |
φ330mm |
| Swing over carriage |
φ195mm |
| Swing over gap |
φ476mm |
| Width of bed-way |
186mm |
| Distance between centers |
1000mm |
| Spindle taper |
M.T.5 |
| Spindle bore |
φ38mm |
| Step of speed |
Variable |
| Range of speed |
low: 70~480rpm |
| high: 480~2000rpm |
| Head |
D1-4 |
| Metric thread |
26kinds (0.4~7mm) |
| Inch thread |
34kinds(4~56T.P.I) |
| Moulder thread |
16 kinds(0.35~5M.P) |
| Diametral thread |
36 kinds(6~104D.P) |
| Longitudinal feeds |
0.052~1.392 (0.002”~0.0548”)mm/r |
| Cross feeds |
0.014~0.38 (0.00055”~0.015”)mm/r |
| Diameter lead screw |
φ22(7/8”)mm |
| Pitch of lead screw |
3mm or 8T.P.I |
| Saddle travel |
1000mm |
| Cross travel |
170mm |
| Compound travel |
74mm |
| Compound travel |
95mm |
| Barrel diameter |
φ32mm |
| Taper of center |
M.T.3mm |
| Motor power |
1.5(2HP)Kw |
| Motor for coolant system’s power |
0.04(0.055HP)Kw |
| Machine(L×W×H) |
1920×760×760mm |
| Stand(left) (L×W×H) |
440×410×700mm |
| Stand(right) (L×W×H) |
370×410×700mm |
| Machine |
500/560Kg |
| Stand |
70/75Kg |
| Loading amount |
22pcs/20’container |
| Metal Bench Lathe Machine |
| Model |
CZ1440V |
| Swing over bed |
φ355mm |
| Swing over carriage |
φ220mm |
| Swing over gap |
φ500mm |
| Width of bed-way |
186mm |
| Distance between centers |
1000mm |
| Spindle taper |
M.T.5 |
| Spindle bore |
φ38mm |
| Step of speed |
Variable speed |
| Range of speed |
low : 70~480rpm |
| high: 480-2000rpm |
| Head |
D1-4 |
| Metric thread |
26kinds (0.4~7mm) |
| Inch thread |
34kinds(4~56T.P.I) |
| Moulder thread |
16 kinds(0.35~5M.P) |
| Diametral thread |
36 kinds(6~104D.P) |
| Longitudinal feeds |
0.052~1.392 (0.002”~0.0548”)mm/r |
| Cross feeds |
0.014~0.38 (0.00055”~0.015”)mm/r |
| Diameter lead screw |
φ22(7/8”)mm |
| Pitch of lead screw |
3mm or 8T.P.I |
| Saddle travel |
1000mm |
| Cross travel |
170mm |
| Compound travel |
74mm |
| Compound travel |
95mm |
| Barrel diameter |
φ32mm |
| Taper of center |
M.T.3mm |
| Motor power |
1.5(2HP)Kw |
| Motor for coolant system’s power |
0.04(0.055HP)Kw |
| Machine(L×W×H) |
1920×760×760mm |
| Stand(left) (L×W×H) |
440×410×700mm |
| Stand(right) (L×W×H) |
370×410×700mm |
| Machine |
505/565Kg |
| Stand |
70/75Kg |
| Loading amount |
22pcs/20’container |
| Metal Bench Lathe Machine |
| Model |
CZ1237V |
| Swing over bed |
φ305mm |
| Swing over carriage |
φ173mm |
| Swing over gap |
φ440mm |
| Width of bed-way |
182mm |
| Distance between centers |
940mm |
| Spindle taper |
M.T.5 |
| Spindle bore |
φ38mm |
| Step of speed |
Variable |
| Range of speed |
low:70~520rpm |
| high:520~1700rpm |
| Head |
D1-4 |
| Metric thread |
26kinds (0.4~7 mm) |
| Inch thread |
34kinds(4~56T.P.I) |
| Moulder thread |
|
| Diametral thread |
|
| Longitudinal feeds |
0.052~1.392(0.002”~0.0548”)mm/r |
| Cross feeds |
0.014~0.38(0.0007”~0.0187”)mm/r |
| Diameter lead screw |
φ22(7/8”)mm |
| Pitch of lead screw |
3mm or 8T.P.I |
| Saddle travel |
810mm |
| Cross travel |
150mm |
| Compound travel |
90mm |
| Compound travel |
100mm |
| Barrel diameter |
φ32mm |
| Taper of center |
M.T.3mm |
| Motor power |
1.5(2HP)Kw |
| Motor for coolant system’s power |
0.04(0.055HP)Kw |
| Machine(L×W×H) |
1780×750×760mm |
| Stand(left) (L×W×H) |
400×370×700mm |
| Stand(right) (L×W×H) |
300×370×700mm |
| Machine |
390/440Kg |
| Stand |
60/65Kg |
| Loading amount |
24pcs/20’container |
Product Image
