TW-5I Slit Lamp 1
  • TW-5I Slit Lamp 1

TW-5I Slit Lamp

Model:TW-5I
Brand:Towoo
Origin:Made In China
Category:Electronics & Electricity / Electronic Instrument / Optical Lens & Instrument
Label:ophthalmic , ophthalmic equipment , slit lamp
Price: -
Min. Order:-
Inquire Now Add to Basket

Member Information

Detail

WENZHOU DONGWU OPTICAL INSTRUMENT CO., LTD.

Biz MemberBeijing - China
Live Chat:Last Online:20 Mar, 2019

Product Description


specifications:TW-5I Slit Lamp
•Characteristics
•This product is an down-side light source type slit lamp, the quality is stable.
•Specifications
Model TW-5I TW-5IB
Total Magnification 10X, 20X 4X~18X
Objectives Magnification 1X, 2X 0. 4X~1.8X(Zoom Objectives)
Work Distance 105mm 100mm
Imaging Pixels 470 thousand (795×596)
Signals Output Video Signals, USB Digital Signals
Microscope Type Converging Stereoscope, Pupil Distance 55 to 75mm
Widefield Eyepieces WF10X Eyepieces Magnification: 10X, Field number: Φ21
Slit Width 0~10mm Continuously Adjustable
Slit Height 1~8mm Continuously Adjustable
Slit Angle 360º Continuously Adjustable
Slit Inclination Angle Elevation 0~20º,Left and Right -6º~+6º
Slit Horizontal Revolving Angle Angle of Left and Right Revolving 30º
Light Spot Diameter Φ0.2, Φ1, Φ2, Φ4, Φ6, Φ8, Φ10 Continuously Adjustable
Filter Heat Absorption, Grey, Redfree, Cobalt blue
Illumination Bulb 12V30W Halogen Bulb
Input Voltage 220V/50HZ (110V/60HZ)
Watch Bulb Wine LED
Range of Rise or Drop of Slipway 0~30mm
Move Range of Slipway Left and Right: 105mm, Front and Back: 85mm
Fluctuate Move Range of Jaw Part 80mm

Product Image

TW-5I Slit Lamp 1
Img 1
