blister packing machine

Model:-
Brand:-
Origin:-
Category:Industrial Supplies / Packaging Related Machine
Label:blister packing , blister packaging , gauze packaing
Price: ¥1 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

Qingdao Hiking Industry Co., Ltd

Biz MemberShan Dong - China
Live Chat:Last Online:24 Feb, 2021

Product Description

Description:
It is used to package one-off medical products, such as injectors, needles, and infusers , medical dressing products, gauze, bandages and meat products.
Feature:
1-Most of the components are made of stainless stee.
2- Controlling system: Mitsubishi PLC
3-Touch screen: Wenyew
4-Driving system:, Mitsubishi server
5-Pneumatic components: SMC,ORIGA,MINDMAN,
6-Vacuums: BUSCH
7-Photocell: Omron
8-Double row packaging is available
Specification:
1-Packaging film:
Upper film: dialyzing paper, DuPont Tyvek and other plastic film
     Lower film: PP/PE , PA or PVC PET
2-Material Roll size:
Upper film: Width 405-415mm, Core diameter: 3"  Max. diameter : ≤400mm
Lower film: Width 421-422mm, Core diameter: 3"  Max. diameter : ≤400mm
3-Max. blister depth: 80mm
4-Max width of the product: 400mm
5-Min width of the product: 19mm
6-Capacity:
PP/PE or PA (lower film)                       15 moulds/min
PVC or PET  (lower film)                        10 moulds/min
Vacuum packaging                                 8 moulds/min
Filling-nitrogen packaging                      8 moulds/min
7-Compressed air: ≥0.6 Mpa
8-Power: 3 phase AC 380V 50Hz   15KW
9-Dimension:  7300mm x 1100mm x 1800mm
10-Weight: 2000kg
Optional equipment:
1-  Flexible printer:
2-  Mould
3-  Waste film collecting device

Product Image

blister packing machine 1
Img 1
blister packing machine 2
Img 2
blister packing machine 3
Img 3
blister packing machine 4
Img 4
blister packing machine 5
Img 5
