Detailed Product Description


1.PCB factory directly
2.PCB fast prototype
3.PCB components assembly
4.PCB SMT processing
5.ISO9001/UL/ROHS


Special futures

· Thickness: 1.6mm

· Application: industry equipment or projecting apparatus

· Minimum trace size: 0.1mm

· Minimum drill: 0.15mm

· With blind and buried holes

· Layers: 1 to 28

· Board finished thicknesses: 0.2 to 7.0mm

· Materials: FR-4, CEM-1, high Tg, halogen-free, Rogers,F4B, Aluminum base,94V0, 94HB

· Maximum finished board size: 550 x 1100mm

· Minimum hole size: 4mil (0.1mm)

· Minimum trace width/space: 3.5/3.5mil

· Surface finishes/treatments: HASL, lead-free HASL, immersion gold, gold plating, immersion silver, immersion tin and OSP

· Copper thicknesses: 0.5 to 6oz

· Solder mask colors: green, yellow, black, white, red and blue

· Copper thickness in hole: >18um

· Inner packaging: plastic bag (vacuum packing)

· Outline tolerance: ±0.13mm

· Hole size tolerance: (PTH) ±0.076 and (NPTH) ±0.05mm

· With UL and ROHS marks

· Special requirements: buried and blind vias, impedance control, via plug, BGA soldering and gold finger
