| Model: | - |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Industrial Supplies / Machinery / Heat Exchange & Air Conditioners |
| Label: | capillary tube mat , capillary heat mats , radiant cooling mat |
| Price: |
US $10
/ sq.meter
|
| Min. Order: | 50 sq.meter |
| Last Online:05 Aug, 2025 |
About Our Company:
• The largest and most established capillary mats manufacturer in China
• Variety of spacings from 5 to 40mm as well as special widths
• Mature production team. Skilled technology. Strict quality control.
• Use only leading German production equipment to ensure the high quality
• The largest manufacturer of capillary tube mats covers 15000m with 7-production lines.
The CAPILLARY TUBE MATS Models We produced
|
Model Material Collector tube Capillary tube Spacing of capillaries(A) Length of capillary mat (L) Width of capillary mat (B) Water contents Total weight with water Exchange surface Heating Capacity Cooling Capacity |
H-10 Polypropylene (PP-R) 20 x 2.0mm 4.3 x 0.8mm 10mm 500-12000mm 1000mm 0.64L/ sq.m 1500g/ sq.m 1.35m2/sq.m 90w/m2 85w/m2 |
H-20 Polypropylene (PP-R) 20 x 2.0mm 4.3 x 0.8mm 20mm 500-12000mm 1000mm 0.32L/ sq.m 750g/ sq.m 0.68m2/sq.m 85w/m2 80w/m2 |
H-40 Polypropylene (PP-R) 20 x 2.0mm 4.3 x 0.8mm 40mm 500-12000mm 1000mm 0.16L/ sq.m 375g/sq.m 0.38m2/sq.m 50w/m2 45w/m2 |
H-30 Polypropylene (PP-R) 20 x 2.0mm 3.4 x 0.5mm 30mm 500-12000mm 1000mm 0.15L/ sq.m 370g/sq.m 0.35m2/sq.m 50w/m2 45w/m2 |
|
Model Material Collector tube Capillary tube Spacing of capillaries(A) Length of capillary mat (L) Width of capillary mat (B) Water contents: Total weight with water: Exchange surface Heating Capacity Cooling Capacity |
U-5 Polypropylene (PP-R) 20 x 2.0mm 4.3 x 0.8mm 5mm 500-6000mm 1000mm 1.28L/ sq.m 3000g/ sq.m 2.7m2/sq.m 120w/m2 100w/m2 |
U-10 Polypropylene (PP-R) 20 x 2.0mm 4.3 x 0.8mm 10mm 500-6000mm 1000mm 0.64L/ sq.m 1500g/ sq.m 1.35m2/sq.m 90w/m2 85w/m2 |
U-20 Polypropylene (PP-R) 20 x 2.0mm 4.3 x 0.8mm 20mm 500-6000mm 1000mm 0.32L/ sq.m 750g/sq.m 0.68m2/sq.m 85w/m2 80w/m2 |
U-15 Polypropylene (PP-R) 20 x 2.0mm 3.4 x 0.5mm 15mm 500-6000mm 1000mm 0.29L/ sq.m 560g/ sq.m 0.71m2/sq.m 85w/m2 80w/m2 |
Introduction of Capillary Tube Mats
Capillary tube mat system is an innovative technology developed to replace the conventional radiator heating and air conditioning systems. It is made of Polypropylene. It consists of plastic tubes with an external diameter of only 4.3mm and two collection pipes with diameter of 20mm. The mats are supplied in lengths of 1m to 12.0m and variable widths up to 1.0m.
To heat or cool rooms, hot or cold water runs through the capillary tube mats system to exchange heat with the space air by radiation. They ensure a quick dissipation of the cooling load or a quick supply of the heat requirement. Due to the large exchange surfaces, large energy quantities can be transmitted with low temperature differences between the active room surface and the room air.
With the advantage of good flexibility,the capillary tube can be installed on roof, wall, and floor, under the surface decorative materials.
