| Model: | XP04~08 |
|---|---|
| Brand: | XP |
| Origin: | Made In China |
| Category: | Industrial Supplies / Other Industrial Supplies |
| Label: | Electromagnetic Chuc , generating suction c , Hydraulic Vacuum Gri |
| Price: |
US $6309
/ pc
|
| Min. Order: | 1 pc |
| Last Online:27 Jun, 2025 |
### **Product Features**
- **Special Magnetic Circuit Design**: Features a high air-gap magnetic flux density. The coil is made of aluminum wire, and the coil protection plate is constructed from rolled high-manganese steel plate with excellent wear resistance and impact strength.
- **Lightweight & Energy-Efficient**: Designed with low self-weight, low energy consumption, high lifting capacity, and long service life.
- **Advanced Insulation System**: The insulation structure is optimized, utilizing true vacuum drying and vacuum resin potting processes to enhance both electrical and mechanical performance of the coil. The insulation material achieves a special heat-resistant grade of C.
- **Control Flexibility**: Typically operates via constant voltage control. Upgrading to strong magnetic control can further enhance lifting capacity.
- **Simple & Reliable Structure**: Suitable for various lifting equipment applications.
---
### **1. Suction Force**
The electro-permanent chuck delivers exceptionally strong adsorption force of **16 kg/cm²**, with **uniform and adjustable magnetic distribution**, making it ideal for heavy-duty mechanical processing, roughing, and precision machining. In contrast, conventional electro-permanent chucks exhibit weaker suction force with uneven distribution, failing to meet the demands of high-intensity mechanical operations.
---
### **2. Machining Precision**
The electromagnetic chuck maintains adsorption force without requiring continuous power connection, enabling uninterrupted operation without heat generation. This prevents workpiece thermal deformation while ensuring high machining precision across all surfaces due to its strong and uniform magnetic field. Ordinary chucks, however, need constant power supply—prolonged operation generates heat, causing workpiece deformation and reduced magnetic force, ultimately compromising machining accuracy.
---
### **3. Operational Performance**
- **Electromagnetic Chuck**: Supports continuous 24/7 operation (over 20 hours/day) without failure or maintenance requirements.
- **Conventional Electromagnetic Chuck**: Magnetic force degrades after approximately six months of use. Standard electromagnetic chucks can only operate a few hours daily, frequently malfunction, and necessitate frequent internal component replacements and maintenance.
---
### **4. Work Efficiency**
- **Ordinary Electro-Permanent Chuck**: Requires extensive workpiece adjustment time, accounting for 40%-50% of the total machining process. Frequent positioning errors lead to high scrap rates and severely reduced efficiency.
- **Electromagnetic Chuck**: Equipped with automatic auxiliary positioning, enabling workpiece clamping/release in just **0.3 seconds** with a single button press. This dramatically improves production efficiency.
