Applications: household oven, steamer, brasing oven, particle furnace, industrial oven, air compressor, temperature measurement instrument, heat meter, industrial equipment control, aerospace, high-speed rail, railway track, wind power generation, charging pile, new energy motor and voltage transformer, etc.

Features: food grade SS304 shell, waterproof and moistureproof, screw for a easy installation

Characteristics:

      Accuracy:class 1/3B,class A,class B

      Working Temperature Range:-50℃~+200℃

      Insulation Voltage:1500VAC,2sec

      Insulation Resistance:500VDC≥100MΩ

      Curve of Characteristics:TCR=3850ppm/K

      Communication Mode:two-wire system,three-wire system

Product Drawing:

 Note:1. 0508 needle naked terminal,      2. 26AWG200℃300V siliver plated thre core transparent sheathed cable

           3. Epoxy resin,                                4. Chips:PT100/PT1000,

           5. SS304 shell
