| Model: | YJRN-650 |
|---|---|
| Brand: | Outlook |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Optical Lens & Instrument |
| Label: | Airport professional , Thermal imaging bird , Bird repeller |
| Price: |
-
|
| Min. Order: | 1 pc |
| Last Online:09 Dec, 2024 |
Yuan Jin thermal imaging laser bird repellent instrument manufacturers
Laser part
Laser power 850mw±10mw
Laser wavelength 532nm/ green
The launch range is 1200 meters
Launch Angle 5-10°
Divergence Angle 1.5mrad
Outlet spot diameter 6mm
Laser output power fluctuation ±10mw/h
Horizontal lock 12 speed
probe
The pixel pitch is 12um
Resolution 640x480
Sensitivity ≤40mk f/1.0/300K,
Response band 8-14um
Lens
Focal length 50mm/f0.1
Focusing mode manual adjustment
Field of view Angle 8.2x6.1
System
Display LCD
Resolution 5.6 inches 1920*1080
Image enhancement Foreground automatic/background automatic/linear
Image polarity White heat/black heat/brown/red heat/iron red/rainbow /
Image sharpness 1-9
Digital doubling fast 1X-2X-4X-/ stepless 50%-400%
Cross coordinates have
6 cross colors/auto/white/black/red/green/blue
Hot spot tracking has
Electronic compass has
The pitch Angle is
Angle of inclination
Laser ranging option
400000 photos /40 hours of video
It's in the picture
Startup time 5 seconds
The extension interface is TYPE-C
Tripod interface is available (tripod is optional)
Protection class IP56
physics
Shell material Metal material
Battery 26650
Working hours: 4 hours
Operating temperature -24 ~ 50
Storage temperature -40°~60°
| Specifications: | YJRN-650 640*480 |
|---|---|
| Advantages: | 1. Far Jin thermal imaging laser bird repelling device and viewing and driving in one, during the day and night can laser drive birds, especially when you can't see birds in the dark night, the bird repelling mirror of far Jin optical drive has played a great role, and the thermal imaging part can find the target, so as to achieve the purpose of driving 2. The all-in-one machine is designed for the integration of night detection and drive device 3. The cross cursor indicates the target coaxial; 4. Watch the screen flip from multiple angles; 5. Multi-function menu: photography, video, false color, brightness/contrast adjustment, power display; 6. There are many ways of use, such as hand, side grip, grip three different operations; 7. The driving device is modular design and can be disassembled and used separately; 8. One key trigger drive device; 9. It is also equipped with night walking lights and warning lights, which also play a role in protecting their own safety for the staff |
