18650 21700 10S4P 36V Lithium ion Battery Pack
Custom high-end Lithium ion Solutions by selecting the best cells, self-designed smart BMS, UL approved cabels and other components.
| Item | Specification |
| Model | 10S4P |
| Nominal Voltage | 36V (customized) |
| Nominal Capacity | 20Ah (customized) |
| Charge Voltage | 42V |
| Max. Charge Current | 5A |
| Max. Continuous Discharge Current | 20A~30A |
| Discharge Cut-off Voltage | 25V |
| BMS Safety Function | Cell balancing, over-charge, over-discharge,
over temperature, short-circuit protection |
| Cycle Life | 80% capacity remaining after 1000 cycles |
| Weight (max.) | 2.9kg |
| Dimension(max.) | (L)220mm*(W)86mm*(T)75mm approx. |
| Operating Temperature | Charge: 0~45℃
Discahrge: -20~60℃ |
