| Model: | Y81T-315 |
|---|---|
| Brand: | HUAPENG |
| Origin: | Made In China |
| Category: | Industrial Supplies / Metallurgy Machinery |
| Label: | press machine , aluminum baler , metal bailer |
| Price: |
US $25000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:16 Sep, 2023 |
Application：
Y81T-315 Push Out Hydraulic Scrap Metal Baling Machine is capable of extruding various metal waste,steel turnings and alloy, waste copper,aluminum profiles,stainless steel, scrapped car body and other shapes of metals scrap. It makes high density bales, square,octagon, cylinder different shapes are available.
By this way, the cost of transportation and burning loss can be reduced a lot. It also makes much efficient storage.
Y81T metal baler machine is mainly used in metal plants,recycling yards,waste recovery and metal refining industry. Size of compressing chamber and finished bale can be customized.
General parted design and compact design for different layout space. Operation can be manual operation and PLC automatic remote control.
Features & advantages：
1) Hydraulic drive, no need special foundataion
2) Compact design, installation free and less floor space
3) Pressing force ranges from 125T to 2000T
4) Customized bale & chamber box size
5) Hardox steel NM500 for whole wearing plate
Application :
◆ Fe, Al, Cu, Cr-Ni Scraps
◆ Ferrous and non-ferrous
◆ Aluminium Extrusions, UBC, Profiles
◆ Rebars, Sheets, Buckets and other Mixed Scraps
|
Model |
Main cyl force (ton) |
Feed box size(L×W×H)(mm) |
Bale size (W×H)(mm) |
Bale weight (kg) |
Power (kw) |
|
Y81T-1250 |
125 |
1200×700×600 |
300×300 |
50~70 |
15 |
|
Y81T-160A |
160 |
1600×1000×700 |
400×400 |
100~180 |
22 |
|
Y81T-160B |
160 |
1600×1200×800 |
400×400 |
100~200 |
22 |
|
Y81T-200A |
200 |
1600×1200×800 |
400×400 |
120~220 |
22×2 |
|
Y81T-200B |
200 |
1800×1400×800 |
300×300 |
180~350 |
22×2 |
|
Y81T-250A |
250 |
2000×1400×900 |
300×300 |
200~400 |
22×2 |
|
Y81T-250B |
250 |
2000×1750×1000 |
500×500 |
200~450 |
22×2 |
|
Y81T-315A |
250 |
2000×1750×1200 |
500×500 |
250~500 |
45×2 |
|
Y81T-315B |
315 |
2500×2000×1200 |
600×600 |
400~700 |
45×2 |
|
Y81T-400 |
400 |
3000×2000×1200 |
600×600 |
500~800 |
45×4 |
|
Y81T-500 |
500 |
3000×2000×1200 |
500×500 |
500~800 |
45×3 |
| Payment Terms: | T/T /LC |
|---|---|
