| Model: | - |
|---|---|
| Brand: | GoodFtth |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Telecommunication & Broadcasting / Network Communications Equipment |
| Label: | simplex cable , duplex cable , multicore cable |
| Price: |
¥299
/ km
|
| Min. Order: | 1 km |
| Live Chat: | Last Online:18 Oct, 2023 |
Application:
Indoor distribution;
For patch cords and pigtails;
For communication equipment.
Feature:
Soft and flexible;
Excellent flame retardant performance;
Excellent tensile&crush strength;
Cable sheath options:PVC,LSZH,OFNP,etc.
Mechanical Characteristics:
|
Fiber Count |
Cable Dimension (mm) |
Cable Weight (kg/km) |
Tensile Strength (N) |
Crush Load (N/100mm) |
Min.Bending Radius (mm) |
Temperature Range (℃) |
|||
|
Long Term |
Short Term |
Long Term |
Short Term |
Dynamic |
Static |
-20~+60 |
|||
|
1 |
1.6 |
2.2 |
40 |
80 |
100 |
500 |
50 |
30 |
|
|
1 |
1.8 |
3.0 |
40 |
80 |
100 |
500 |
50 |
30 |
|
|
1 |
2.0 |
3.6 |
60 |
100 |
100 |
500 |
50 |
30 |
|
|
1 |
2.4 |
5.0 |
60 |
100 |
100 |
500 |
50 |
30 |
|
|
1 |
2.8 |
6.5 |
80 |
150 |
100 |
500 |
60 |
30 |
|
|
1 |
3.0 |
7.4 |
80 |
150 |
100 |
500 |
60 |
30 |
|
Optical Characteristics:
|
|
|
G652D |
G657A1 |
G657A2 |
G.655 |
62.5/125 |
50/125 |
|
Attenuation
|
@850nm |
|
|
|
|
≤3.0dB/km |
|
|
@1300nm |
|
|
|
|
≤1.0dB/km |
||
|
@1310nm |
≤0.36dB/km |
|
|
||||
|
@1550nm |
≤0.22dB/km |
≤0.23dB/km |
|
|
|||
|
Bandwidth
|
@850 |
|
|
|
|
≥500MHZ·km |
|
|
@1300 |
|
|
|
|
≥600MHZ·km |
≥1000MHZ·km |
|
|
Numerical Aperture |
|
|
|
|
|
0.275±0.015NA |
0.200±0.015NA |
|
Cut-off Wavelength |
|
≤1260nm |
≤1480nm |
|
|
||
