| Model: | - |
|---|---|
| Brand: | yongguang |
| Origin: | Made In China |
| Category: | Industrial Supplies / Rubber & Plastics Machine |
| Label: | leno mesh bag machin , leno mesh bag loom , leno bag machine |
| Price: |
-
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:21 Mar, 2024 |
|
1 |
Working width，double flat |
600-850mm |
|
2 |
Number of shuttles per machine |
4 |
|
3 |
weft density |
10-24pcs/10cm |
|
4 |
Speed |
0-120RPM |
|
5 |
Warp feeding |
Motor |
|
6 |
Inner diameter of Bobbin |
38mm |
|
7 |
Bobbin length |
230mm |
|
8 |
Max. bobbin diameter |
100mm |
|
9 |
Number of Warp yarns |
512pcs |
|
10 |
Normal rating of main motor |
2.2kw |
|
11 |
lift motor power : |
22N |
|
12 |
winding motor power: |
Torque motor |
|
13 |
Total power |
3Kw |
|
14 |
Installed size (mm) |
10500* 2400* 3200 |
|
15 |
weight |
1700KGS |
