| Model: | RH-HS-APD-DA |
|---|---|
| Brand: | Reful |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Optical Fiber, Cable & Wire / Optical Fiber |
| Label: | Fiber array , APD , Detector array |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:11 May, 2024 |
Combined with high precision 2D fiber optic array, our company introduces 2D high speed detector array. The product has accurate positioning function, which can detect the surface array of the detected object and output high precision position information. It is suitable for the detection, monitoring and imaging of high-speed moving objects and high-speed reaction processes.
This product separates the 2D fiber optic array probe from the electric control part, the probe has the advantages of small size, anti-radiation, anti-electromagnetic interference, high and low temperature resistance. It has a unique advantage for the detection of narrow space in harsh environment.
The product can also provide bias power supply and transimpedance amplifier (preamplifier), and is equipped with the main amplifier, waveform discrimination and other circuits according to demand.
Product parameter
|
Wavelength range |
700-1700nm |
|
Diameter of photosensitive surface |
80μm |
|
Maximum gain |
20@VR=VBR-1V-3dB |
|
Cut-off frequency |
1.4Hz@VR=V BR-3V |
|
Dark current |
10nA@VR=V BR-3V |
|
Junction capacitance |
0.7pF@VR=V BR-3V，f=1MHz |
