| Model: | RH-2D-T-FA |
|---|---|
| Brand: | Reful |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Optical Fiber, Cable & Wire / Optical Fiber |
| Label: | Fiber array , Thermostable |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:29 Apr, 2024 |
Thermostable Fiber Arrayis encapsulated with nanoscale inorganic adhesive technology, and the overall device can withstand high temperatures up to 250°C. The array end face can even withstand temperatures up to 800°C, making it not only maintain the usual high precision arrangement of Reful high-end fiber optic arrays, but also have excellent temperature resistance. This product can help users to complete the data acquisition with location information in high temperature environments, and can be accurate and highly dense energy transmission in high temperature environments. Its compact size and high density energy transfer capability are a great advantage in small and harsh environments.
Our high-temperature resistant fiber optic arrays can meet the needs of high-temperature, high-pressure, and high-vacuum environments, providing high-performance optical transmission solutions for industrial and military applications.
Product parameter
|
Project |
Specification |
Accuracy |
|
Wavelength |
190nm-2400nm |
|
|
Fiber arrangement shape |
Any shape |
|
|
Pitch of line Fiber array |
≥50um |
±0.0005mm |
|
Pitch of 2D Fiber array |
≥80um |
±0.002mm |
|
Length of Fiber array |
≤100m |
±500mm |
|
Length of Fiber array |
≤2m |
±2mm |
|
Number of Fiber array |
300Pcs*300Pcs |
Dark Fiber Rate ≤ 1%, |
|
Number of Fiber array |
40Pcs*40Pcs |
0， Dark fiber ratio 0, |
|
Array end service temperature without vacuum requirement |
≤800℃ |
|
|
Operating temperature of array end with vacuum requirement |
≤300℃ |
|
|
Air leakage rate |
≤1.7*10-8Pa.m3/S |
|
|
Vibration resistance frequency range 0-2000(Hz) |
15.8g grms |
Three-directional sine |
