| Model: | GPS170-190 |
|---|---|
| Brand: | HarmonyWOLRD/OEM/ODM |
| Origin: | Made In China |
| Category: | Computers & AV Digital / Computers / Embedded Computer & SCM |
| Label: | IP Network Server , GPS Broadcast Server , GPS Succession |
| Price: |
US $1360
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:08 Jul, 2023 |
IP Network Server GPS Broadcast Server GPS Succession IP Webcast server -Industrial Computer (IPC)
| model | GPS-150 | GPS-170 | GPS-173 | GPS-190 | |||
| Chassis material | Aluminum panel+galvanized steel plate black/silver | ||||||
| Chassis button | Volume knob adjustment (optional one-button alarm button), microphone interface, 2*USB2.0 | ||||||
| source | 300-350W industrial switching power supply with PFC function | ||||||
| fingerboard | Pull-out mouse | not have | Pull-out mouse | Pull-out mouse | |||
| Display parameters | |||||||
| Screen size | 15" | 17" | 173" | 19" | |||
| resolution ratio | 1024*768 | 1280*1024 | 1920*1080 | 1280*1024 | |||
| Screen Scale | 4:3 | 5:4 | 16:9 | 5:4 | |||
| luminance | 450cd/m2 | 250cd/m2 | 250cd/m2 | 250cd/m2 | |||
| touch screen | Resistance screen touch | ||||||
| Platform configuration | |||||||
| a main board | industrial motherboard | Compatible with Micro-ATX motherboard, standard ATX motherboard | |||||
| CPU | Celeron J1800/J1900/N2840processor | sustain LGA1155 3th Intel Corei3/i5/i7/Celeron/Pentium processor | sustain LGA1150 4th Intel Core
i3/i5/i7/Celeron/Pentium processor |
||||
| internal storage | DDR3/DDR3L1333/1600 dual-channel support up to 16GB | ||||||
| storage | 1*SATA2.0 | 4*SATA2.0 | |||||
| support system | WIN7, 8, 102012 system | ||||||
| USB | 4*USB2.0 | 2*USB2.0
2*USB3.0 |
|||||
| Serial port | 6*COM | 2*COM | |||||
| Network interface | 2*LAN gigabit network interface | 1*LAN Gigabit/ 2*LAN Gigabit | |||||
| PS/2 | 1 | ||||||
| Display interface | VGA,DVI | VGA,HDMI/VGA,DVI | |||||
| expand | not have | 2*PCI(PCle to PCI) | |||||
| LPT Parallel port | not have | Optional | |||||
| audio frequency | 1*MIC-in,1*Line-out | 1*MIC-in,1*Line-out,1*Line-in | |||||
| working temperature | 0°C~50°C;5%~90%(Non-condensing state) | ||||||
| Storage environment | -20°C~60°C;5%~90%(Non-condensing state) | ||||||
For more industrial computer, download catalog
