En10305 DIN2391 Precision Seamless Steel Tubes, E215, E235, E255, E355 St35, St45, St52 Pipe
Product Description
Seamless Steel Pipe/Tube
--Precise custom outer diameter and inner diameter
--Tight tolerances, resulting in reduced machine time / Dimensional accuracy
--Smooth and Clean OD and ID surfaces
--Excellent machining characteristics
--Wider range of physical properties attainable through process and annealing options
1.Product Description /Specifications
|
Production Range |
Outer Diameter:10-120mm (0.4 inch - 4.7 inch) |
|
Wall Thickness:1-20mm (0.04 inch - 0.78 inch) |
|
|
Material / Grade |
Carbon Steel: GB/T 8162 & 8163 & 3639: 10#, 20#, 35#, 45#, 55#, Q235B, Q235C, CF53, A105 ASTM A519: 1010, 1020, 1026, 1035, 1045, 1050 DIN17121/EN 10297-1, DIN1629/DIN2391/EN 10305-1: C10/CK10, C22/CK22, C35/CK35, C45/CK45, CF53 JIS3441/JIS3444/JIS3445: STKM11A, STKM12A/STKM12B/STKM12C, STKM13A/STKM13B/STKM13C JIS G4051: S10C, S20C, S25C, S35C, S45C, S55C |
|
Alloy Steel: GB/T 8162 & 8163 & 3639: 16Mn(Q345B), 20Cr, 40Cr, 15CrMo, 20CrMo, 28CrMo, 30CrMo, 35CrMo, 42CrMo, 20CrMnTi, 40MnMoV, 20Mn2, ZF6, 16MnCr5, 20MnCr5, 38Mn2V, 09CrCuSb(ND) ASTM A519: 5120, 5140, 4130, 4135, 4140 DIN17121/EN 10297-1, DIN1629/DIN2391/EN 10305-1: ST52, EN10084-1998 20Cr4, 41Cr4, 15CrMo4, 25CrMo4, 35CrMo4, 42CrMo4, 16MnCr5 JIS3441/JIS3444/JIS3445: SCM432/SCRRM3, SCM4 JIS G4053: JIS SCr420, JIS SCr440, SCM415, SCM420 |
|
|
Tolerance |
Tolerance ±0.15mm,Superior products ±0.05mm, Can be customized according to customer's requirements |
|
Technique |
Cold Drawn / Cold Rolled |
|
Shape |
Round |
|
Further Processing for Steel Tubes |
Final Annealing, Cutting, Chamfer, Threading, Inner diameter or Outer Diameter Lathe, Surface Shot Blasting, Laser Marking |
