Walk-in Chamber for Complex Salt Spray Test (Temperature controllable)

Model:HMBE820912-15
Brand:HarmonyWOLRD/OEM/ODM
Origin:Made In China
Category:Electronics & Electricity / Electronic Instrument / Test Bench
Label:Walk-in Chamber , Salt Spray Test , Temperature TEST
Price: -
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

HMWTECH CO.,LTD

Biz MemberJiang Xi - China
Live Chat:
Last Online:17 Mar, 2023

View all products. (757)

Product Description

Relevant standards requirement

  1. Test Object: battery pack andsystem.
  2. Refer GB/T4 part 5.5.2 test method, test according to GT/T2423.17 test conditions.
  3. The salt solution was made up with sodium chloride (chemically pure and analytically pure) and distilled or deionized water，Its concentration is (5 + 1)% (mass fraction).
  4. (35 ± 2) ℃, the measured pH value is between 6.5-7.2.
  5. Placed the test objects in the salt spray chamber for cycling test. Each cycling duration for 24h. Spray salt solution to the test object for 8 hours under the temperature of (35± 2) ℃ , remain for 16 hours. Between the forth and the fifth hour in one cycles should be according to test requirement in GB/T 28046.1-2011, test mode with 3.2.
  6. Total 6 cycles testing.
  7. Salt spray test is not necessary for the test objects being installed in passenger, l age or cargo compartments.

Standard

  • UL 2580



Technical Parameters

Product Name Complex Salt Spray Test Chamber
Model No. HMBE8209 12(m³) HMBE820915(m³)
Internal Dimension W2000 X D3000 X H2000 mm W2500 X D3000 X H2000 mm
External Dimension W2400 X D5000 X H3000 mm W2900 X D5000 X H3000 mm
Max Load 1000KG for battery pack
Temp. Range 0℃～+85℃
Temp. Fluctuation ±0.5℃
Temp. Deviation 2℃
Spray Capacity 1~2mL/80cm2/hr (Collect at least 16 hours, take the average )
Spray Pressure 1.00±0.01kgf/cm²
Resolution Temp: 0.01℃, Humidity:0.01%R.H.
Humidity Range 30%–98%R.H.

Humidity Fluctuation ±3%R.H.
Potion PH Neutral 6.0～7.0      Acidity 3.0～3.1
Spray Solution PH Neutral 6.5～7.2    Acidity 3.1～3.3
Test Time Range 1S ～ 9999H  (Settable)
Control Mode Touch screen programmable control PLC, networking; mobile phone APP alarm; with USB interface, with RJ485 interface can be connected to computer control, exclusive network control software. Remote monitoring and data acquisition.
Internal material Acid and alkali resistant SUS316 material
External material Cold and heat resistant steel plate with spray coating
Cooling Mode Air cooling / water cooling
Total Weight Approx 7 Tons
Power Supply AC 380V, 55KW
Other Auxiliary Functions *Main-subsidiary type trolley for the specimen in and out of the test chamber.*Explosion-proof, Pressure relief, Smoke Exhaust, Fire extinguishing, Video monitoring.
