Model:	UTM50K1/2
Brand:	HarmonyWOLRD/OEM/ODM
Origin:	Made In China
Category:	Electronics & Electricity / Electronic Instrument / Test Bench
Label:	Tensile TestER , Testing Machine , Tensile Tester
Price:	-
Min. Order:	1 pc

Inquire Now Add to Basket

Member Information

HMWTECH CO.,LTD

Biz MemberJiang Xi - China

Live Chat:

Last Online:30 Mar, 2024

Product Description

1. Powerful test function, with different fixtures, it can carry out a variety of test requirements to meet the needs of users.

2. The software has more powerful functions. Various test results and test curves can be displayed and automatically marked in the interval. It can be upgraded at any time to realize positioning shift, fixed force, fixed time, repeated fatigue testing, etc.

3. The design of the machine is beautiful, generous, easy to operate, and the software has strong scalability and high accuracy.

4. Servo motor drive, high precision ball screw drive, low failure rate and simple maintenance.

SPECIFICATIONS:

Item	UTM50K1	UTM50K2
Capacity (MAX)	50KN (optional 10N~50KN range force sensor)
Control mode	full computer control mode, powerful software function
Power unit	N, kN, gf, kgf, lbf, kP, tf (SI), tf (long), etc.
Length unit	mm, cm, Inch, m, km, um, etc.
Power resolution	1/500,000;
Accuracy	±0.1%
Travel resolution	1/500,000mm
Accuracy	±0.1%
Effective stroke	700mm; (customizable)	1200mm; (customizable)
Speed range	0.01~500mm/min; (customizable)
Test space	420mm left and right (customizable)
Shutdown mode	overload shutdown, emergency stop button, automatic shutdown of specimen damage, automatic shutdown of upper and lower limit settings
Machine power	Servo motor drive
Machine size (W×D×H)	88×66×208cm	108×66×208cm
Net weight of machine	420KG	480KG
Power	400W
Power supply	220V 50~60HZ
Machine equipment	1 USB communication line, 1 software
Optional accessories	tensile fixture, compression fixture, etc.; (purchase different fixtures according to different test standards)

Product Image

Img 1

Img 2

Img 3

Img 4

Img 5

Img 6

Img 7

Img 8

Img 9

Img 10

Img 11

Img 12

Img 13

Img 14

Img 15

Img 16

Img 17

Img 18

Img 19

Img 20
