DESCRIPTION
The HMSAS series salt spray test chamber produced by our company is one of the "three-proof" test equipment for artificial climate environment. It is the defense industry, scientific research institutes, light industry and electronics, architectural coatings, bicycles, motorcycles and automobile manufacturing industries. It conducts environmental adaptability and reliability tests on metal material protective layers, various parts, electronic components and industrial products One of the essential important equipment. This product can perform neutral salt spray test (NSS), acetic acid salt spray test (ACSS), copper salt accelerated acetic acid salt spray test (CASS).
Test meets standards
GB/T2423.17 (IEC60068-2-11); GB/T2423.18 (IEC60068-2-52); GB/T10125; ISO 9227; GB/T13543; ASTM B117; IEC60068-2-11-1981; JIS H8502 , CNS4159, CNS4158 and other test methods.
Features
1. The whole machine is made of imported PVC&PP hard plastic board, with solid structure, acid and alkali resistance, high temperature resistance, corrosion resistance, and never aging. It is suitable for various tests such as neutral salt spray NSS, acetic acid test ASS, copper acetate CASS, etc. Claim.
2. Using plastic precision nozzle and cone spray device, the mist falls uniformly and quickly, and the nozzle has a long service life and does not crystallize.
3. Using LCD button type intelligent temperature control instrument, multiple PID automatic calculation, good control accuracy.
4. The flow rate of salt water and the pressure of compressed air are adjusted by flow meter and high pressure valve to ensure uniform salt mist precipitation.
5. The manual water refilling system is adopted, and the water level is insufficient with automatic replenishment function to ensure that the test is not interrupted.
SPECIFICATION
|
HMSAS series model |
HMSAS108 |
HMSAS270 |
HMSAS480 |
HMSAS800 |
HMSAS1440 |
|
|
Inner box size mm |
W |
600 |
900 |
1200 |
1600 |
2000 |
|
D |
450 |
600 |
850 |
850 |
950 |
|
|
H |
400 |
500 |
500 |
550 |
600 |
|
|
Outer box size mm |
W |
1130 |
1460 |
1900 |
2300 |
2700 |
|
D |
630 |
910 |
1150 |
1150 |
1350 |
|
|
H |
1070 |
1280 |
1500 |
1550 |
1600 |
|
|
Working room volume (L) |
108 |
270 |
480 |
800 |
1440 |
|
|
Salt water tank capacity (L) |
15 |
25 |
90 |
90 |
120 |
|
|
Laboratory temperature |
（NSS ACSS）Test temperature： 35℃±1℃/ (CASS) Test temperature：50℃±1℃ |
|||||
|
Saturated barrel temperature |
（NSS ACSS）Test temperature： 47℃±1℃/ (CASS) Test temperature：63℃±1℃ |
|||||
|
Brine temperature |
35℃±1℃ /50℃±1℃ |
|||||
|
Test solution |
NSS：purified water + sodium chloride (PH6.5～7.2)/ CASS：purified water + sodium chloride + copper chloride（PH3.0～3.2） |
|||||
|
Compressed air pressure |
2kgf/cm2 |
2kgf/cm2 |
6kgf/cm2 |
6kgf/cm2 |
6kgf/cm2 |
|
|
Power supply |
AC 220V，1Ф, 50HZ |
|||||
Configuration
1. Technical data: operation manual, product certificate, warranty card, etc.
2. Deliver a pack of wet ball gauze
3. Distribution of 4 bottles of sodium chloride
4. Distribution of a gas supply pipe
5. Distribution of one exhaust pipe joint
6. A set of delivery sealing plugs
7. Distribution of a salt water bucket
8. A set of V-shaped racks and material sticks for delivery materials
Optional accessories
1. Control panel: Button type and LCD touch screen operation panel are optional
2. Working mode: steam heating (water boiling type) / anhydrous temperature control (dry burning type) optional
3. Salt water concentration meter
4. Air compresso
