BRTR07WDS5PC/FC five-axis servo manipulator

BRTR07WDS5PC/FC series is suitable for taking out finished products and nozzles of various horizontal injection molding machines of 50T-200T. For special product applications such as inner inserts, precise positioning, fast speed, long life, and low failure rate, the installation of manipulators can increase production capacity (10-30%), reduce product defect rates, ensure the safety of operators, reduce labor, and achieve precise control Increase production, reduce waste, and ensure delivery.Five-axis drive and control integrated control system: fewer signal lines, long-distance communication, good expansion performance, strong anti-interference ability, high repeat positioning accuracy, can control multiple axes at the same time, simple equipment maintenance, and low failure rate.

Power Capacity (KVA) Applicable Molding Machine (ton) Drive Method Fixture Type 3.5 50T-200T AC Servo Motor Four Suction Two Holds Horizontal Stroke (mm) Pull Out Stroke (mm) Up and Down Stroke (mm) Maximum Load (kg) 1300 P :300-R:125 720 3 Take out time (sec) Full cycle time (sec) Air consumption (NI/cycle) Weight (KG) 1.02 4.75 4 270

 MainSpecificationS5:Five-axis driven by AC Servo Motor(Traverse-axis、Vertical-axis+Crosswise-axis).

The above-mentioned cycle time are the results of our company's internal test standard. In the actual application process of the machine, they will vary according to the actual operation.

  A        B       C    D    E

1200 2280 720 570 1300

   F    G      H   I    J

327 200 240 90 322

   K      L      M   N

125 1020 325 300
