SPECIFICATION:

FEATURES:

The use of PC control, servo power, mechanical adjustment is simple, many movement stations, hollow/inductance coil winding machine can make single, multi-layer, round wire, flat wire and other kinds of complex shape of hollow coil inductors.

The upper control system adopts domestic top CNC controller, high-performance dual-core CPU, Windows interface, 10-inch LCD screen, clear and intuitive picture, stable operation, easy to learn, easy to understand, easy to operate.

The power system is imported high-precision servo motor, which matches the CNC control system organically. Make its three axis movement has accurate synchronization, reliable control, accurate movement and displacement, can produce all kinds of high requirements of torsion spring products.

Air coil winding machine can be matched with automatic wire feed frame; Empty core coil winding machine can be equipped with enameled wire peeling machine, intelligent temperature control tin stove, can realize coil inductance peeling, tin, forming at one go.

Automatic wire clamp and cut system, layer winding, material unloading and cleaning of the tool during each cycle.

ADVANTAGES:

Multi-function microcomputer design, easy to set data, permanent storage, and has automatic speed limit, pause editing, both ends of the deceleration and other functions.

The wireline shaft is driven by a stepping motor with a constant current circuit, with fast wireline speed and high precision.

The position of the winding point can be input by teaching and display the current position of the spool.

The use of copper guide wheel, wear resistance.

The winding point can be set in sections. Width, line distance and speed, etc., in order to achieve the purpose of multi-section and multi-speed.

APPLICATION:

Automatic Coil winding Machines are used for winding the small EI transformers, signal transformers, inductors, filter choke coil, relays, current contactors, valve coils, solenoid coils, telecom bobbin transformers. It can complete the coils without any one operator in fully automatically.

PRACTICAL APPLICATION :

TRAINNING CUSTOMER TO OPERATE WINDING MACHNE :

1.All service engineers with 10 years experience are gotten special technology training, who can deal with various breakdown problem.
2.Guide the user to use accurately and how to maintain the Fully Automatic Winding Machine   .
Provide free consultation about production process technology of electronic products.
3.In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English manual, video, guiding on line.
