|Origin:||Made In China|
|Category:||Industrial Supplies / Plate Making & Printing Machine|
|Label:||Jar Cup Tube printer , Screen Printers , auto screen printer|
|Min. Order:||1 pc|
Fully servo-controlled automatic screen printing machine for plastic or glass bottles jars cups tubes container
It can screen print from 1 to 17 colours
Fast, Innovative, Convenient and Green
This full servo printing machine can print round, oval, square, polygonal plastic and glass products. The visual positioning system can locate the bottle bottom or bottle body.
Compact look and reduced overall dimensions make it suitable for small-sized companies as well.
screen printing head can be replaced to hot stamping head,make multi color screen printing and hot stamping in one line.
Completely servo-assisted, it can print up to 17 colours on plastic or glass multi-format containers.
Thanks to servo-assisted printing adjustments that afford a 0.1mm adjustment tolerance between colours.
1.Auto loading and unloading with multi axis servo robot.
3.Auto flame treatment before printing and UV LED curing after printing .
UV LED lamps and high-efficiency engines assure reduced energy consumption, Zero ozone emission and reduced CO2 production.
4.Auto printing system with all servo driven:printing heat ,mesh screen frame ,rotation etc.
all jigs installed with servo motors for rotation (no need gears, easy and fast products changeover)
5. Quick and easy change over from one product to another. All parameters automatic setting simply in touch screen. it only takes 20 minutes to debug each color.
6.All ethercat servo motors with industrial PLC control&touch screen operation system,internet cable connection available,easy for fucture maintenance and ungrading.
7.Adopt linear high-speed precision CCD scanning : for cylindrical products without registration point, repeat print to be double colors.
8. Well built machine house with CE standard safety design.
9.Can use UV ink or thermoplastic ink.
