Woven bag sewing machine sewing machine adopts advanced ultrasonic sewing technology and wireless sewing, which is fast and beautiful. It is the professional equipment of wireless sewing machine for producing and making woven bag products. The edge melting treatment is carried out in the form of holes. The edge melting and cutting effect is soft, does not take off wires, does not break, does not damage, does not burr, does not damage the original characteristics of the material, has no irritation to the skin, and is in line with environmental protection and human health.

Output power 2000W

Operating frequency 20KHz
Power supply 50 / 60Hz 220VAC / 8A
Pneumatic cylinder φ 75*80mm / φ 40*50mm
Suture speed 20 ± 2m / min
Overall dimension 1200 * 550 * 1200 (mm)
Weight 120kg

The working principle is to use the high-frequency oscillation to transmit the sound wave from the welding head to the welding surface of the working object, instantly make the molecules of the working object rub and reach the plastic melting point, so as to complete the rapid dissolution of solid materials and complete the welding. Its joint strength is close to a whole piece of continuous material. As long as the joint surface of the product is designed to match, there is absolutely no problem with complete sealing.
Using special alloy steel to make flower wheel mould, various complex flower patterns can be developed according to customer needs; The welding head is wear-resistant and has a long service life. The assembly and disassembly of the pattern is convenient and easy. The eccentric core adjustment is flexible, fast and high levelness.
