Stainless Steel Wire Zoo Mesh for Avairy Mesh monkey

Model:stainless steel
Brand:bossmetal wire rope mesh
Origin:Made In Azerbaijan
Category:Construction & Decoration / Building Steel & Structure
Label:stainless steel , zoo mesh , stainless steel wire
Price: US $16.98 / pc
Min. Order:1 pc
Inquire Now Add to Basket

Member Information

Detail

BOSS METAL AND PLASTIC CO.LTD

Biz MemberHe Bei - China
Live Chat:Last Online:24 Oct, 2022

Product Description

Stainless Steel Zoo Mesh

 Our products are widely used in zoos and therefore referred to by our customers as Zoo mesh. Our products are known as zoo fence,enclosure fence & birds aviary mesh and so on...Design for where the safety and light weight structure required.Smooth surface suit the people & animal touch.

Customized Diamond Ferruled Stainless Steel Wire Rope Cable Handrail Balcony Infill Mesh,rod and tubular frame systems,Nets design and install assistant by Candurs cable mesh systems China.



DecorRope flexible Diamond Ferruled Stainless Steel Wire Rope Cable Handrail Balcony Infill Mesh is assembed by seamless ferrules and stainless steel wie rope.Diamond mesh when it is stretched at 60° angle ( Option: 90° angle ).

Advantages

DecorRope flexible Diamond Ferruled Stainless Steel Wire Rope Cable Handrail Balcony Infill Mesh has characteristic property and capacity to replace other steel wire mesh in certain application.Sometimes better.

  • Unique design idea.3D-structure,Flexible,elegant,discreet,filigreed,multifuncational.
  • Light weight,High open area % .
  • Corrosion resistant,allows strongh airflow.
  • Total pro-environment,recyclable,no toxic,non flammable.
  • Maintenaance free,don't ask any special cleaning & coating.
  • At least 10 years guaranteed.

Panel Shape

Customized Rectangular panel shape.Trapezoid panel shape,Triangular panel shape,circle panel shape,and other special shape.Customized net height and length.

Easily Install

DecorRope flexible Diamond Ferruled Stainless Steel Wire Rope Cable Handrail Balcony Infill Mesh is main installed on tube frame, perimeter cables or wire rod with special border design Available 30 types different border plans to meet different install required.

Application

  1. Building Facade screens,
  2. Green wall systems
  3. Balustrade & Railing
  4. Bird protection netting,
  5. Security platform fence. Isolate fence,Garden fence,
  6. Animal enclosures in zoo
  7. And so on...

Specification

material

stainelss steel 304 316 316L etc.

wire diameter

1.0 - 3.2mm

feature

flexible, high-Strength

technique

woven wire mesh

mesh rolls size

1x30m 2x30m 4x30m or according to clients' requirements

structure

7*7 or 7*19

surface

flat and WYight

Advantages of stainless steel cable mesh 1. Excellent flexible performance. 2.Virtually indestructible. 3.Most impacting resistant and WYeaking resistant force, most resisting rain, snow, hurricane 4.High strength, strong toughness,free angles curving and fold, easy for transportation and installment. 5.Service life is over 30 years. Application of stainless steel cable mesh * Zoo construction: animal enclosures, aviary mesh, bird cage, wildlife park, marine park, etc. * Protective device: playground fence, acrobatic show protection net, wire rope mesh fence, etc Architecture safety net: stair/balcony railing, balustrade, safety net, anti-fall net, etc. * Decorative net: garden decoration, wall decoration, interior decoration net, outdoor decoration, green wall (plants climbing support) For aviary/zoo The main installation accessories: stainless steel standard parts, stainless steel wire rope, stainless steel collar, stainless steel buckle and so on. After installation, no maintenance is required in the later period

Model

Structure

Rope Diameter

Mesh Opening

2076

7*7 or 7*19

2.0mm

76*76mm

2051

7*7 or 7*19

2.0mm

51*51mm

1651

7*7 or 7*19

1.6mm

51*51mm

1638

7*7 or 7*19

1.6mm

38*38mm

1238

7*7 or 7*19

1.2mm

38*38mm

1230

7*7 or 7*19

1.2mm

30*30mm

1225

7*7 or 7*19

1.2mm

25*25mm

The Stainless Steel Wire Rope Fence Mesh  ferrule type is rhombus mesh, has excellent flexible performance, virtually indestructible, most impacting-resistant and WYeaking resistant force, most resisting rain, snow and hurricane.

For Protecting Mesh Specifications of two kinds of Stainless Steel Wire Rope Net Material: SUS302, 304, 316, 316L Wire diameter: 1.0mm-3.0mm Structure:7*7,7*19. Mesh Opening Size:1"*1",2"*2",3"*3",4"*4".

Our Flexible stainless steel cable mesh products are supplied in two main series: Inter-woven and Ferrule Type.

Weaving Types Handwoven, Open type buckle, Closed type buckle. 1:Flexible stainless steel cable mesh (Knotted type) Inter-woven mesh are hand-woven which was also called hand-woven mesh is made from fine s.s.wire rope .

The rope construction is 7 x 7 or 7 x 19 and made from AISI 304 or AISI 316 material group.

Code

Rope Construction

Rope Diameter

Opening Size

Breaking Force

Inch

mm

Inch

mm

KN

WY-01

7 × 19

1/8

3.2

4.7" × 4.7"

120 × 120

7.38

WY-02

7 × 19

1/8

3.2

4" × 4"

102 × 102

7.38

WY-03

7 × 19

1/8

3.2

3.6" × 3.6"

90 × 90

7.38

WY-04

7 × 19

1/8

3.2

3" × 3"

76 × 76

7.38

WY-05

7 × 19

1/8

3.2

2" × 2"

51 × 51

7.38

WY-06

7 × 7

3/32

2.4

4" × 4"

102 × 102

4.18

WY-07

7 × 7

3/32

2.4

3.6" × 3.6"

90 × 90

4.18

WY-08

7 × 7

3/32

2.4

3" × 3"

76 × 76

4.18

WY-09

7 × 7

3/32

2.4

2.4" × 2.4"

60 × 60

4.18

WY-10

7 × 7

3/32

2.4

2" × 2"

51 × 51

4.18

WY-11

7 × 7

5/64

2

3" × 3"

76 × 76

3.17

WY-12

7 × 7

5/64

2

2.4" × 2.4"

60 × 60

3.17

WY-13

7 × 7

5/64

2

2" × 2"

51 × 51

3.17

WY-14

7 × 7

5/64

2

1.5" × 1.5"

38 × 38

3.17

WY-15

7 × 7

1/16

1.6

3" × 3"

76 × 76

2.17

WY-16

7 × 7

1/16

1.6

2" × 2"

51 × 51

2.17

WY-17

7 × 7

1/16

1.6

1.5" × 1.5"

38 × 38

2.17

WY-18

7 × 7

1/16

1.6

1.2" × 1.2"

30 × 30

2.17

WY-19

7 × 7

1/16

1.6

1" × 1"

25 × 25

2.17

WY-20

7 × 7

3/64

1.2

2" × 2"

51 × 51

1.22

WY-21

7 × 7

3/64

1.2

1.5" × 1.5"

38 × 38

1.22

WY-22

7 × 7

3/64

1.2

1.2" × 1.2"

30 × 30

1.22

WY-23

7 × 7

3/64

1.2

1" × 1"

25 × 25

1.22

WY-24

7 × 7

3/64

1.2

0.8" × 0.8"

20 × 20

1.22

2:Flexible stainless steel cable mesh (Ferrule type) The ferrule type series are sub-divided into aluminum alloy mesh ,stainless steel ,tinned copper and nickled copper mesh by the material of the ferrule. The ferrule type mesh, are more used in fields like balustrades on staircases, large barrier fences, and building facade trellis systems.

Code

Rope Construction

Rope Diameter

Aperture

Breaking Force

Inch

mm

mm

kN

WY-01

7 × 19

1/8

3.2

120 × 208

7.38

WY-02

7 × 19

1/8

3.2

100 × 173

7.38

WY-03

7 × 19

1/8

3.2

90 × 156

7.38

WY-04

7 × 7

3/32

2.4

100 × 173

4.18

WY-05

7 × 7

3/32

2.4

90 × 156

4.18

WY-06

7 × 7

3/32

2.4

80 × 139

4.18

WY-07

7 × 7

3/32

2.4

70 × 121

4.18

WY-08

7 × 7

5/64

2

100 × 173

3.17

WY-09

7 × 7

5/64

2

90 × 156

3.17

WY-10

7 × 7

5/64

2

80 × 139

3.17

WY-11

7 × 7

5/64

2

70 × 121

3.17

WY-12

7 × 7

1/16

1.6

80 × 139

2.17

WY-13

7 × 7

1/16

1.6

70 × 121

2.17

WY-14

7 × 7

1/16

1.6

60 × 104

2.17

WY-15

7 × 7

1/16

1.6

51 × 87

2.17

WY-16

7 × 7

3/64

1.2

80 × 139

1.22

WY-17

7 × 7

3/64

1.2

60 × 104

1.22

WY-18

7 × 7

3/64

1.2

50 × 87

1.22

WY-19

7 × 7

3/64

1.2

40 × 69

1.22


Payment Terms:TT
