Over View

ZS5000 series 4G Router is the internet of thing mobile broadband router and a machine to machine(M2M) industrial cellular router.High data speed via 4G network, 3G/2G backward compatible.It is an ideal wireless data transfer device for applications transferring large data load because of ultimately fast transfer speed in 4G network reaching up to 150Mbps download and up to 50Mbps upload.

ZS5000 series 4G router with Dual SIM Dual Module function,could backup network between the two SIM to ensure continuous connection. It is well-suited for M2M Connectivity in harsh or remote enviornment because of its r ed metal casing,LED status display,wide voltage range (7.5V DC to 32V DC) ,mounting ear installation and operating range of -30℃ to 75℃.It is widely used in industrial automation, outdoor video surveillance, self-service terminals, monitoring and other industries.

Industrial Design

• High-performance dual-core hardware platform
• R ed and compact metal housing
• High and low temperature resistance(-30℃~75℃),durable
• Wide voltage range (7.5V DC to 32V DC)
• Strong electromagnetic interference Resistance,passed the EMC test required for CE certification
• Support  mounting ear for industrial

Stability

• Built-in watch dog,Multi-link detection
• Always online,automatically reconnect when disconnected to ensure continuous connection
• LCP/ICMP/flow/heartbeat check,ensure network usability

Basic Features

• Support APN and VPDN wireless private network access in
• WAN port support PPPoE,static IP,DHCP client
• Support 2.4G WiFi
• Web/Management platform support,easy configure
• Local and remote management (configuration,status,firmware upgrade,etc.)
• Support VPN:GRE,PPTP,L2TP,IPSec,EOIP,N2N VPN,OpenVPN
• Support DMZ,Port forwarding,Static NAT
• Support DHCP Server
• Support Dynamic DNS (DDNS)
• DTU serial communication function,1 x RS232 or RS485
• Support QoS,NTP
• Schedule reboot

Optional Features

• Load balancing,used for failover or backup between two networks
• GPS capability for fleet management or other tracking application
• Support SNMP network management
