| Model: | PHP-2020B |
|---|---|
| Brand: | Hoting |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Components / Integrated Circuit |
| Label: | Glazed potentiometer , Dielectric antennas , Ceramic metallizatio |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:06 Feb, 2024 |
Application:
Widely used in Ecigarette lighter ceramic heater sheet, Porous ceramic, Ceramic capacitors, Resistors, Thick film circuits, Ceramic circuits, Filters, Glazed potentiometers, Dielectric antennas, Ceramic metallization, RFID, Automotive oil level sensors, Tension sensor , Air quality sensors, Pressure sensors( Piezoresistive, Capacitive), Integrated LED lamp holders, Thick film printing machine, Technical indicators. Piezoelectric ceramic components, LED ceramic substrates, LTCC, MLCC, Optical filter, Ceramic thick film circuit, Solar wafer, Chip components and Electronic parts printing process manufacturing.
Specification:
1. High precision printing effect through reasonable design, fine parts processing and PLC program setting.
2. Convenient one touch screen frame clamp.
3. High precision roller screw keep squeegee scraper even speed.
4. Using micro direction adjustment keep printing position accurate and instant.
5. Precision manufacturing alloy workplatform to keep printing evenness.
6. Installing adjustable squeegee pressure regulator.
7. Compact equipment and low noise design improve the influence of working area and environment.
Parameter:
| Model | PHP-2020B |
| Max printing size | 200 X 200mm |
| Worktable size | 280 X 280mm |
| Printing speed | 500 cycle/hour |
| Max frame size | 450 X 450mm |
| Printing pressure | 0-50kgf |
| Printing table adjustable range | X/Y ±10mm Z=0-50mm |
| Printing table tolerance | In/out ±10um |
| Printing table flatness | ±10um |
| Printing repeat tolerance | Front and back side 0 - 9999 times |
| Screen fixed | Cylinder clamp |
| Air pressure | 6kg/cm2 adjustable |
| Weight | Approx. 460kg |
| Power | 220V X 1ph X 1KW |
| Dimension (W X D X H) | 790 X 1190 X 1200mm |
| Payment Terms: | TT/LC/DP/DA |
|---|---|
