| Model: | cuag-gb |
|---|---|
| Brand: | Guangbo |
| Origin: | Made In China |
| Category: | Metallurgy , Mining & Energy / Metallurgy & Mining / Metallic Powder |
| Label: | Silver-coated Copper , nano coated powders , conductive raw mater |
| Price: |
¥2500
/ kg
|
| Min. Order: | 0.05 kg |
| Live Chat: |  | Last Online:10 Nov, 2023 |
Sliver-coated Copper powder
Application
Apply to manufacture conducting paste, conducting printing ink, conducting resin, membrane switch and other intermediate and low-temperature paste, which can be instead of silver powder used in electronic industry.
Product Features
1. Uniform particle size
Product specification
|
Specification |
Mean Particle Size (μm) |
Specific Surface Area (m2/g) |
Particle Size Distribution (μm) |
Ag Content (wt%) |
||
|
D10 |
D50 |
D90 |
||||
|
CuAg-GB0500 |
0.5 |
1.05-1.70 |
0.80-1.80 |
15-30 |
2.80-3.30 |
15-30 |
|
CuAg-GB1000 |
1.0 |
0.90-1.10 |
2.10-2.60 |
10-30 |
5.20-5.80 |
10-30 |
|
CuAg-GB5000 |
5.0 |
0.25-0.30 |
3.30-3.80 |
10-20 |
8.80-10.30 |
10-20 |
|
CuAgF-GB0500 |
- |
1.90-2.00 |
1.50-1.70 |
15-30 |
5.00-5.60 |
15-30 |
|
CuAgF-GB1000 |
- |
0.80-0.95 |
2.50-3.20 |
10-30 |
5.80-6.30 |
10-30 |
|
CuAgF-GB5000 |
- |
0.35-0.60 |
3.20-3.80 |
10-20 |
8.80-10.30 |
10-20 |
Different specifications products can be customized.
