Copper Powder
Application
Apply to manufacture the termination and internal electrode of Multi-Layered Ceramic Capacitor and electronic pastes.
Features
1. Uniform particle size
2. Spherical shape
3. High crystallinity
4. Good dispersion property
Product specification
|
Specification |
Mean Particle Size (μm) |
Specific Surface Area (m2/g) |
Particle Size Distribution （μm） |
Tap Density (g/cm3) |
||
|
D10 |
D50 |
D90 |
||||
|
Cu-GB0301 |
0.30 |
1.69-2.69 |
≤0.70 |
≤1.20 |
≤2.50 |
≥2.60 |
|
Cu-GB0501 |
0.50 |
1.10-1.70 |
≤0.85 |
≤1.50 |
≤3.00 |
≥3.00 |
|
Cu-GB1001 |
1.00 |
0.50-1.00 |
≤1.50 |
≤2.50 |
≤5.00 |
≥3.50 |
|
Cu-GB2001 |
2.00 |
0.48~0.56 |
≤1.80 |
≤2.80 |
≤5.50 |
≥4.0 |
|
Cu-GB3501 |
3.50 |
0.34~0.42 |
≤2.50 |
≤4.0 |
≤7.0 |
≥4.50 |
|
Cu-GB5001 |
5.00 |
0.16~0.24 |
≤4.0 |
≤5.50 |
≤9.0 |
≥5.0 |
Products customized available.
