High Pressure Carbon Steel Pipe Fittings 3000BL Forged A105
Brief description of piping fittings
Pipe fittings are the general term for parts and components that serve as connections, controls, directional changes, steering, seals, and supports in the pipe system.
It can be divided into:
1. Pipe fittings used to connect pipes are: flanges, pipe joints, pipe clamps, wire clamps, wire clamps, hose clamps, etc.
2. Fittings that change the direction of pipe: elbow, elbow
3. Fittings for changing pipe diameter: reducing diameter (reducing pipe), reducing elbow, branch pipe base, reinforcing pipe
4. Add pipe fitting for pipe branch: three way, four way
5. Pipe fittings used for pipe sealing: gasket, raw material belt, hemp, flange blind plate, pipe plug, blind plate, head, welding plug
6. Pipe fittings used for fixing pipes: clasp, tug hook, lifting ring, bracket, bracket, pipe clamp, etc.
China is already the world's largest producer and consumer of building materials. Various pipe fittings and flanges are widely used in various fields of life. Hebei Pipefun is a professional pipe fittings manufacturer. You can click here to contact us.
|
Products |
Forged Pipe Fittings |
|
Material |
ASTM:A234-WPB, WP1, WP5, WP9, WP11, WP12, WP22, WP91, WP92, A420, |
|
WPHY42, WPHY52, WPHY60, WPHY65, WPHY70, WP304, |
|
|
WP304L, WP304H, WP316, WP316L, WP321, WP347, WP347H |
|
|
DIN:ST37.0, ST35.8, ST45.8, S235JR, P235GH, P265GH, |
|
|
10CRMO910, 15CRMO, 12CR1MOV |
|
|
Standards |
ASME:ANSI B16.9, ANSI B16.5, ANSI 16.28, MSS-SP-75 |
|
ANSI B16.11 ANSI B16.47 |
|
|
DIN: DIN2605, DIN2615, DIN 2616, DIN 2617, DIN28011 |
|
|
SGP:JISB2311 JISB2312 JISB2313 |
|
|
EN:EN10253-1, EN10253-2 |
|
|
WALL THICKNESS |
SCH10, SCH20, SCH40, SCH80, SCH160, XS XXS STD |
|
SIZE |
1/2''-72'' |
|
APPLICATION |
Constructions, petroleum, chemical industry, power, ship building, metallurgy, water supply and sewage work, light and heavy industry, plumbing and electric etc. |
|
SURFACE |
Shot blasted, rust-proof black oil painted |
|
RADIUS |
1D-10D |
|
CERTIFICATES |
ISO-9001:2000, API, CCS |
|
Production Capacity |
100000 Piece/Pieces per Month |
|
MOQ |
1 piece |
|
Price term |
EXW factory, FOB, C&F and CIF |
|
Payment term |
T/T, L/C, West Union, Money Gram and etc |
|
Export to |
USA, Canada, Australia, France, Spain, Oman, Iraq, Singapore, Vietnam etc |
|
Package |
Standard export wooden case or customized. |
Product Name: High Pressure Carbon Steel Pipe Fittings 3000BL Forged A105
Standard: MSS-SP-75, MSS-SP-97
Size: 1/8"- 4" ,DN10-DN100
Pressure: 2000#,3000#,6000#,9000#
Material: A105, A182 F304/304L, A182 F316/316L, A182 F321, A182 F310S, A182 F347H
Type:SW TH
Certificate: BV, SGS, LOIYD, TUV, and other party alloyed by clients
MOQ: 1 piece
Application: High pressure usage
| Payment Terms: | T/T LC |
|---|---|
