Model: APV-150-24

Constant voltage LED Power Supply.

Input Voltage: 200-240VAC 47-63Hz

Output Voltage: 24V

Output Current:6.25A

Output Rated Power: 150W max

Inrush Current: 70 Amps max. at 230VAC/50Hz,full load

No Load Power Consumption: ＜0.5W

Protections: Short Circuit /Over Current /Over Voltage

/over temperature protection

Short Circuit Protection (SCP) Yes,hiccupmode, auto-recovery

Over Voltage Protection (OVP): Yes,hiccupmode, auto-recovery

Over Current Protection (OCP): Yes,hiccupmode, auto-recovery

Working TEMP.: -30°C-70°C

Working Humidity: 10%-90% RH non-condensing

Storage TEMP.,Humidityand altitude: -40℃ ~+70°C ambient

temperature and a 5% to 95% relative humidity range throughout

an altitude range of -60 meters to +5000 meters AMSL.

Certificates and approvals: CE CB SE OHS

MTBF: 100Khours minimum at full load at 25℃ ambient

Dimension: 205 x 70 x 45mm (L x W x H)

Packing: 1.2kg; 15pcs./ctn; ctnweight and dimensions: 18.5kg;

45.5 x 29.5 x 19cm

Model NO/input voltage/output voltage/output current/output power/Efficiency/ Dimension

APV-150-24/200-240VAC/24VDC/6250mA/150W/92%/203x70x45mm

APV-150-36/200-240VAC/36VDC/4160mA/150W/93%/203x70x45mm

APV-150-48/200-240VAC/48VDC/3125mA/150W/93%/203x70x45mm
