| Model: | SLG70 |
|---|---|
| Brand: | FLD |
| Origin: | Made In China |
| Category: | Industrial Supplies / Fishery Machine |
| Label: | fish feed machine , fish food extruder , pelelt machine |
| Price: |
US $25000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:02 Nov, 2020 |
Working Principle:
The extruder is provided with a set of screw and screw sleeve, which have the function of mixing and kneading.After the raw material enters the expanded cavity, the material is squeezed, frictional, shear and other effects between the screw sleeve, and the internal pressure keeps rising, up to 4Mpa, and the temperature keeps rising, up to 140 degrees Celsius.With the sharp increase of temperature and pressure within 3-7s, the material's tissue structure changes, making starch further gelatinize, protein denaturation, crude fiber destruction, killing salmonella and other harmful bacteria.High temperature and high pressure materials come out from the outlet, the pressure is suddenly released in an instant, and part of the moisture occurs flash evaporation. After cooling, the material presents a loose and porous structure, while after expanding, the material presents a ball shape, flocculent shape or coarse debris shape.
3. Raw Materials Of Floating Fish Feed Pellet Making Machine:
The raw material is: Flour,corn meal,soybean meal,maize meal ,meat meal,bone meal,fish meal etc.
Fitness: about 60-80mesh which were crushed and mixed.
Moisture content: about 20%-25%.
4.Floating Fish Feed Pellet Making Machine Parameter:
| Model | Capacity
(t/h) |
Main Power
(kw) |
Feed Power
(kw) |
Screw diameter
(mm) |
Cut Power
(kw) |
Dimension
(mm) |
| DT50 | 0.06-0.08 | 11 | 0.4 | 50 | 0.4 | 1470*1100*1250 |
| DT60 | 0.12-0.15 | 15 | 0.4 | 60 | 0.4 | 1470*1120*1250 |
| DT70 | 0.18-0.25 | 18.5 | 0.4 | 70 | 0.4 | 1650*1400*1300 |
| DT80 | 0.30-0.35 | 22/27 | 0.4 | 80 | 0.6 | 1800*1450*1300 |
| DT90 | 0.40-0.45 | 30/37 | 1.1 | 90 | 0.6 | 2100*1450*1350 |
| DT120 | 0.50-0.60 | 55 | 1.1 | 120 | 1.5 | 2400*1950*1600 |
| DT135 | 0.70-0.80 | 75 | 1.1 | 133 | 2.2 | 2550*2050*1650 |
| DT160 | 1.00-1.20 | 90 | 1.5 | 155 | 2.2 | 3100*2650*1800 |
| DT200 | 1.80-2.00 | 132 | 2.2 | 195 | 3.0-4.0 | 3100*2850*1900 |
Company Information
JINAN DATONG EXTRUSION MACHINERY Co., Ltd Is a professional fish feed machine suppliers.We supply single machines and production lines including Dry type fish feed machine and Wet type fish feed machine .
1. We Are Manufacturer for Fish Feed pellet machinery.
2. Alibaba Assessed Gold Supplier.
3. Inspected by the Inspection Institution of Bureau Veritas Certification.
4.100% QC inspection Before Shipment.
5. Best Quality & Best Service with Competitive price.
Our Services
The machine is backed by a one-year warranty. During the warranty period, the machine will receive free accessories in addition to natural damage, human negligence or other non-human factors that are caused by the vulnerability or quality of the parts. If there are quality problems in design, equipment installation, etc. during the warranty period, our company will respond within 24 hours, and timely send technical personnel to provide video support services.Provide lifelong paid services to the equipment, provide spare parts and spare parts to solve your worries.
Remarks: The above warranty period starts from the time the goods leave the factory.
Packaging & Shipping
PACKAGE:
Standard export carton packing.
Export standard wooden case or Whole contaciner
DELIVERY TIME:
5-15 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
