| Model: | LGK7-130 |
|---|---|
| Brand: | HUARONG |
| Origin: | Made In China |
| Category: | Industrial Supplies / Tools / Other Tools |
| Label: | cutting machine , cnc cutting machine , cutter |
| Price: |
¥574
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:08 Sep, 2020 |
Outline and function
Function: plasma arc cutting
Application Scope: cutting stainless steel, alloy steel, foundry iron, carbon steel, Copper, Aluminum, Manganese, Titanium, clad plate and so on.
Performance Feature
Digit display can preset cutting parameters accurately and the current is stepless.
With advanced soft switch high frequency inverter technology and super-power IGBT module switch device circuit,the machine is reliable.
100% arc-striking success rate, stable and stiff arc, smooth incision, excellent technological performance.
The machine has all signal output required by CNC control and is suitable for automatic cutting.
With high duty cycle,this machine can keep working a long time under maximum current.
|
LGK7-130 |
|||
|
Name |
Unit |
Parameter |
|
|
Voltage/frequency |
V/Hz |
3～380V±15% 50/60Hz |
|
|
Rated input capacity |
KVA |
24 |
|
|
Rated input current |
A |
36 |
|
|
Power factor |
- |
0.86 |
|
|
Rated output current |
A |
130 |
|
|
Rated output voltage |
V |
132 |
|
|
Rated duty cycle |
% |
100/40℃ |
|
|
Output no-load voltage |
V |
310 |
|
|
Output current range |
A |
30～130 |
|
|
Quality cutting thickness (steel ) |
mm |
25 |
|
|
Max cutting thickness (steel) |
mm |
45 |
|
|
Plasma gas usage |
- |
Compressed air |
|
|
Working gas pressure scope |
MPa |
0.45-0.55 |
|
|
Efficiency |
% |
90 |
|
|
Insulation class |
- |
F |
|
|
Shell protection degree |
- |
IP21S |
|
|
Torch cooling |
- |
Air-cooled |
|
|
Arc-striking mode |
- |
Non-contact arc-striking |
|
|
Dimension(L×W×H) |
mm |
670×325×595 |
|
|
Net weight |
Kg |
55 |
|
|
Low-carbon steel |
Quality cutting |
mm |
25 |
|
Cut-off ability |
mm |
45 |
|
|
Max perforation |
mm |
22 |
|
|
Stainless steel |
Cut-off ability |
mm |
32 |
|
Quality puncture |
mm |
20 |
|
|
Aluminum |
Cut-off ability |
mm |
32 |
|
Quality puncture |
mm |
20 |
|
| Payment Terms: | EXWCHENGDU |
|---|---|
