P3mm Indoor LED Display High-Performance Large LED Video Signage Wall Screen Panel
3.0mm pixel pitch LED display, 1,100 nits brightness, 3840Hz+ refresh rate
Silu`s P3mm indoor LED display is particularly designed for a variety of installations at any events, such as hanging to the floor or to stacking, fixed on a wall. Multiple accessories are provided to help the fast and easy setup of displays across a versatile range of environments.
The P3mm indoor advertising lightweight LED panel display is designed for indoor rental or fixed installations, it delivers high contrast ratio, superior colour fidelity and uniformity to form the ultimate high-resolution 3mm pixel pitch HD LED video display.
P3mm Indoor LED Display LED Module Configuration
*P3mm Indoor LED Display 192mm LED Module Pic. 01*
*P3mm Indoor LED Display 240mm LED Module Pic. 02*
P3mm Indoor LED Display LED Cabinet Configuration
P3mm Indoor LED Display 480mm LED Panel Pic. 01*
*P3mm Indoor LED Display 576mm LED Cabinet Pic. 02*
*P3mm Indoor LED Display LED Video Wall Pic. 03*
P3mm Indoor LED Display Description
Silu`s P3mm HD large video signage screen raises vivid, clarity, durability and reliability to high levels of performance with a superior high-resolution pixel pitch of 3.0mm and a sturdy lightweight die-cast aluminium LED panel.
The P3mm high-performance indoor LED screen panel is a fast setup and teardown type, easy to maintenance. Its superb contrast ratios and brilliant colour reproductions make it an equally effective in rental and installation applications of all sizes.
Super Quality Image and High Refresh Rate
The P3.0mm indoor LED display is widely used for the high-end video show and broadcasting occasions, which supports for high refresh rate output. And drive and decoding quick response help to get rid of the ghost.
The broadcasting videos and images are stable with no scanning line, and the edge of the image is sharp and clear when dealing with dynamic pictures, all of which can present the original picture information truly and accurately.
Close Viewing Distance and Wide Viewing Angle
Less than 3 meters minimum viewing distance and more than 160° super wide horizontal and vertical viewing angle cover more potential customers.
CNC Die-Casting Technology and Seamless Splicing LED Cabinet
The P3mm indoor LED display screen comes with slimline and lightweight cabinets that are made of heavy-duty aluminium laser cut to precision.
The P3mm LED display cabinets can be connected by two or four sets of locks in each direction, which makes it truly seamless splicing capability.
Lateral positioning beads and bottom positioning pins ensure flatness in each direction between the cabinets.
Advanced COB Technology Glue Cover Protection*
COB (Chips on Board), is a new technology of LED packaging for the LED light engine. Multi LED lamps are packaged together in a PCB as one lighting LED module. When it lights up, it looks like a whole lighting panel.
P3mm Indoor LED Display Specification
|P3mm HD LED Video Screen|
|LED Brand||Nationstar or Cree or Nichia|
|Pixel Density||111,111 Pixels/m²|
|LED Module||192/240mm x 192/240mm (7.6/9.45" x 7.6/9.45")|
|64/80 pixels x 64/80 pixels|
|LED Cabinet||480/576mm x 480/576mm (18.9/22.7"x18.9/22.7")|
|(160/192 pixels x 160/192 pixels)|
|Aluminum: < 10Kg (< 22 Lbs)|
|Working Voltage||AC220V±10%; AC110V±10%|
|Power Consumption||Average 416W/m² / Max 868W/m²|
|Maximum Brightness||> 1,100 cd/m²|
|Refresh Frequency||> 3840Hz/S|
|Change Frame Frequency||60Hz~ >60Hz|
|Drive Mode||1/32 Scanning|
|Total Colors||281 Trillion Colors|
|Grade Level||RGB 65536 Grade|
|Best Viewing Distance||3m~>100m (9.8ft~>328ft)|
|Best Viewing Angle||Horizontally 160° / Vertically 160°|
|Screen Lifetime||> 100,000 hours|
|Protection Level||Front IP43 / Rear IP31|
|Control System ¹||Simple LED Video Control System or Advanced LED Video Processor|
|Ambient Temperature||-40°C ~ 60°C (-30°F ~ 150°F)|
|Input Signal||RF S-Video RGB RGBHV YUVYC etc.|
|Brightness Adjustment||256 levels of each colour (RGB) can be adjusted manually and 8 levels of each colour can be adjusted automatically. Optional control system: 256 levels of each colour can be adjusted 100% automatically. (8bit / 16bit / 18bit / 24bit)|
|Package Material||Wooden Case / Flight Case|
|Warranty ³||2 Years (3 Years for Cree and Nichia)|
