| Model: | Drillstar-FM |
|---|---|
| Brand: | drillstar |
| Origin: | Made In China |
| Category: | Industrial Supplies / Textile Machinery Parts |
| Label: | face mask machine , non woven machine , N95 face mask |
| Price: |
US $80000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:31 Mar, 2020 |
Application:
1. Suitable for producing disposable flat face masks
2. Whether the masks produced by this production line are medically independent of the machine. As long as the masks are sterilized and analyzed, the masks produced by this production line can be used as surgical masks
3. Masks of different sizes and styles can be produced by changing the mold.
4. The production line adopts aluminum alloy structure, with good finish and rust resistant。
5.Only need two days on-site training or video training , machine adjustment and operation can be
finished separately.
Machine functions
1. Automatically Feeding of raw material
2.Raw material shaping and automatically conveying
3. Nose strip automatically cutting off function
4. Mask horizontal edge welding
5. Mask Edge folding
6. Mask Longitudinal edge welding
7. Mask shape completion cutting
8.Mask unloading
|
Technical parameters |
|
|
Ultrasonic frequency |
20KHz |
|
machine diamension |
2400(L)x600(W)x1200(H)mm |
|
loading rack diamension |
1600(L)x550(W)x2000(H)mm |
|
equipment weight |
900kgs |
|
Productivity |
80-100pcs/min |
|
mask specification |
175mm(L)*95mm(W) |
|
power supply |
380V，50Hz±1 |
|
general capacity |
3.5kVA（MAX） |
|
gas supplying system |
Oil-free, water-free clean compressed gas source. |
| Payment Terms: | T/T |
|---|---|
