| Model: | AL-27 min |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Electronics & Electricity / Electronic Instrument / Analysis Instrument |
| Label: | x-ray diffractometer , x-ray , diffractometer |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:27 Dec, 2021 |
It is a functional and miniaturized desktop X-ray diffractometer system, enriched advanced technology of traditional diffractometer,which is designed for industrial production and quality control. It can get accurate qualitative and crystal structure analysis of metal and nonmetal samples. Especially suitable for catalyzer, titanium dioxide, cement, pharmacy and other manufacturing industry.
Main Parameters
|
Rating power (tube voltage, tube current): 600W (40kV, 15mA) or 1200W (40kV,30mA), stability degree: |
600W (40kV, 15mA) or 1200W (40kV,30mA), stability degree: 0.005%
|
|
X-ray tube: Metal ceramic X ray tube, target material: |
Cu, power:2.4kW, focus size: 1×10mm; air cooling or water cooling (flaw>2.5L/min) |
|
Goniometer: Sample level θs-θd,radius of diffraction: |
150mm |
|
Scanning fashion: |
Continuous, stepping and Omg
|
|
Angle scanning range: |
θs / θd dlinkage /single action: -3° -150°
|
|
Minimal stepping wide: |
0.0001°
|
|
Angle repeatable accuracy: |
0.0005° |
|
Angle locating speed: |
1500°/min |
|
Counter: |
Closed proportional counters or High speed one-dimensional semiconductor counter
|
|
Maximal counting rate of linearity: |
≥5 × 105CPS (Proportional), ≥9×107CPS(one-dimensional semiconductor)
|
|
Computer: |
DELL business notebook |
|
Radiation protection: |
Lead and glass cabinet, irradiation safety is better than 1μSv/h
|
|
Integrated stability: |
≤1‰ |
|
Figure size: |
600 × 410 × 670(w × d × h)mm
|
| Price Terms: | FOB shanghai |
|---|---|
| Payment Terms: | TT/LC/DP/DA |
| Packing: | Exporting packaging |
| Lead Time: | within 90 days |
| Standards Certificate: | CE/ ISO |
