| Model: | KSC093D |
|---|---|
| Brand: | LONGXING |
| Origin: | Made In China |
| Category: | Apparel & Fashion / Shoes / Athletic & Sports Shoes |
| Label: | LONGXING , 3D SHOES , RUNNING SHOES |
| Price: |
US $11000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:15 Apr, 2024 |
|
KSC092D-14G |
|
|
Gauge |
14G |
|
Width |
36 inches |
|
System |
One carriage double system |
|
Speed |
Maximum speed 1.4m/s |
|
Racking |
Driving by servo motor, 2 inches left and right |
|
Selection system |
8-segment needle selector, pre-select needle system |
|
Sinker |
Cross-type sinker driven by stepper motor |
|
Automatic parking device |
Yarn break, yarn knot, rewinding, needle broken, pieces completed, overload, designated parking, program error, etc |
|
safety devices |
The whole machine covers the cover that reduces noise and dust, the front and rear cover infrared stop sensor, emergency stop, power cut-off device |
|
Drawing device |
High-position roller, segment adjustment |
|
Needle push mechanism |
Controlled by electromagnets for faster return |
|
Tight tuck |
Tight tuck cam controlled by step motor, segmental tight tuck density control |
|
Machine size and weight |
Volume: length X width X height 2150X865X1850 (mm) Net weight: 680 kg |
|
Power device |
Voltage: AC220V/380V Frequency: 50Hz/60Hz Power: 1.5KW |
