| Model: | MSP-400X |
|---|---|
| Brand: | EASY PRINT |
| Origin: | Made In China |
| Category: | Industrial Supplies / Packaging Related Machine |
| Label: | CNC Multicolor Overp , Servo cursor positio |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:01 Sep, 2021 |
Description:
CNC Multicolor Overprint Screen Printing Machine
| Product name：CNC Multicolor Overprint Screen Printing Machine | |||||
| Item：MSP-400X | |||||
| Details： | |||||
| CNC Multicolor Overprint Screen Printing Machine | |||||
| This machine is high precision overprinting servo screen printing machine . | |||||
| Advantage | |||||
| 1) Don't need any registration point for products . | |||||
| Leuze sensor detect first printing to overprint , to print second color , very high precision . | |||||
| 2) Don'y need any gears , just fixture is enough. | |||||
| Panasonic servo motor instead gear to overprint . | |||||
| Specification | |||||
| Model number | MSP-300X | MSP-400X | MSP-600X | MSP-800X | MSP-1200X |
| (Round)Max Printing diameter | 82 mm | 120mm | 180mm | 250mm | 375mm |
| (Round)Max printing area | 300×260mm | 300×360 mm | 300×570mm | 350×770mm | 420×1170mm |
| Max Workpiece rake | <14° | <14° | <14° | <14° | <14° |
| Air pressure | 6bar | 6bar | 6bar | 6bar | 6bar |
| power | 2.3kw | 2.3kw | 2.8kw | 3.2kw | 3.6kw |
| Voltage | AC110V/220V | AC110V/220V | AC110V/220V | AC110V/220V | AC110V/220V |
| Printing speed | 1300P/H | 1200P/H | 1100P/H | 900P/H | 800PH |
| Machine appearance（mm） | 850×850×1280 | 1080×850×1280 | 1200×1100×1450 | 1300×1180×1450 | 1720×1600×1650 |
| Machine weight | 320kg | 345kg | 500kg | 520kg | 600kg |
