| Model: | HGM |
|---|---|
| Brand: | clirik |
| Origin: | Made In China |
| Category: | Industrial Supplies / Mining Machine |
| Label: | micro powder grindin , ultrafine vertical m , Raymond roller mill |
| Price: |
US $60000
/ set
|
| Min. Order: | 1 set |
| Live Chat: | Last Online:11 Sep, 2019 |
what machine can be used in the limestone milling machine.
you may have questions about it.there are some machines can be used in it.
such as micro powder grinding mill,high pressure suspension grinding mill,cabinet hammer crusher,hammer crusher, HGM80 fine grinding machine,high pressure suspension fine grinding machine,YGM7815 fine mesh grinder,YGM8314 fine milling machine, YGM9517 fine powder grinder,YGM4121 fine powder mill,MTM1600 fine roller mill,big raw material box-type crusher,box-type breaker, high-speed rotary hammer crusher.
what is said above all can be used in the limestone milling machine.
first of all,micro powder grinding is the equipment specializing in producing fine and superfine powder of non-inflammable,non-explosive and brittle materials with Mos's hardness under six.
second,high pressure suspension grinding mill is suitable for processing various non-flammable and non-explosive mineral material with Moh's hardness less than 9.3 and humidity less than 6%,it is widely used in the fileds of metallurgy,construction,chemical industry,mining,highway construction etc.
third,cabinet hammer crusher with feature of large feeding space,it is very suitable for processing big raw material with size 450-1400mm to small granularity below 100mm,which are widely used for mine,cement,building material,chemical industry and so on.
The Main Specifications of Micro Powder Grinding Mill
| model | HGM80 | HGM90 | HGM100 | HGM100A | HGM125 |
| Ring Diameter(mm) | 800 | 930 | 1035 | 1035 | 1300 |
| Ring Number(layer) | 3 | 3～4 | 3 | 4 | 4 |
| Roller Number(piece) | 21 | 24～32 | 27 | 34～36 | 40～44 |
| Main Shaft Speed(r.p.m) | 230～240 | 200～220 | 180～200 | 180～200 | 135～155 |
| Input Size(mm) | ≤20 | ≤20 | ≤20 | ≤20 | ≤20 |
| Finished Size(um/mesh) | 5～47(325-2500) | 5～47(325-2500) | 5～47(325-2500) | 5～47(325-2500) | 5～47(325-2500) |
| Capacity(t/h) | 0.5～4.5 | 0.6～6.5 | 0.7～7 | 1～8.5 | 1.5～12 |
| Overall Dimension(L*W*H,m) | 13.9*4*6.2 | 14.7*4.8*7.2 | 18*4.6*8.6 | 18*4.6*8.6 | 14*9*10.25 |
| Motor Power(KW) | 145～165 | 185～204 | 263 | 263～290 | 380～430 |
