| Model: | PE series |
|---|---|
| Brand: | - |
| Origin: | Made In China |
| Category: | Industrial Supplies / Mining Machine |
| Label: | Movable Jaw Crusher , Mobile Jaw Crusher , mining grader/millin |
| Price: |
-
|
| Min. Order: | 1 pc |
| Live Chat: |  | Last Online:07 Apr, 2024 |
A movable jaw and a fixed jaw compose of the crushing chamber, it completes the material crushing operation just like the movement of the jaw of animals. Jaw crusher is widely used in the crushing of various ores and large materials in mining smelting, building materials, roads, railways, water conservancy and chemical industries and so on. The maximum compressive strength of the crushed material is 320Mpa.
DIFFERENT MODEL
We offer different model for suit your capacity ,if you need any s est please contact us
| Model | Feed size | Max Feeding size(mm) | Capacity
(t/h) |
Power
(kw) |
Weight
(t) |
Dimension
(mm) |
| PE-150*250 | 150*250 | 125 | 1-3 | 5.5 | 0.8 | 720*660*850 |
| PE-200*300 | 200*300 | 180 | 2-6 | 7.5 | 1.2 | 910*750*990 |
| PE-200*350 | 200*350 | 180 | 3-10 | 11 | 1.5 | 1000*870*990 |
| PE-250*400 | 250*400 | 210 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
| PE-400*600 | 400*600 | 340 | 16-60 | 30 | 7 | 1730*1730*1630 |
| PE-500*750 | 500*750 | 425 | 40-110 | 55 | 12 | 1980*2080*1870 |
| PE-600*750 | 600*750 | 500 | 80-240 | 55 | 15.8 | 2070*2000*1920 |
| PE-600*900 | 600*900 | 500 | 50-180 | 55 | 17 | 2190*2260*2300 |
| PE-750*1060 | 750*1060 | 630 | 110-320 | 110 | 29 | 2660*2430*2800 |
| PE-800*1060 | 800*1060 | 640 | 130-330 | 110 | 29.8 | 2710*2430*2800 |
| PE-830*1060 | 830*1060 | 650 | 150-336 | 110 | 30.7 | 2740*2430*2800 |
| PE-870*1060 | 870*1060 | 660 | 190-336 | 110 | 31.5 | 2810*2430*2800 |
| PE-900*1060 | 900*1060 | 680 | 230-390 | 110 | 33 | 2870*2420*2940 |
| PE-900*1200 | 750900*1200 | 850 | 220-450 | 110 | 52 | 3380*2870*3330 |
| PE-1000*1200 | 1000*1200 | 850 | 315-500 | 110 | 55 | 3480*2876*3330 |
