| Model: | 300T |
|---|---|
| Brand: | DAHUA |
| Origin: | Made In China |
| Category: | Industrial Supplies / Rubber & Plastics Machine |
| Label: | 300T press machine , press machine , vacuum press machine |
| Price: |
US $38000
/ pc
|
| Min. Order: | 1 pc |
| Live Chat: | Last Online:12 Aug, 2022 |
Parameter:
| Model | 200Ton | 250Ton | 300Ton | 350Ton | 400Ton | 500Ton |
| Clamping force(Ton) | 200 | 250 | 300 | 350 | 400 | 500 |
| Stroke(mm) | 250 | 250 | 250 | 300 | 300 | 300 |
| Heating plate size(mm) | up 503x508mm
down 554x560mm |
up 600x600mm
down 600x650mm |
up 600x600mm
down 650x650mm |
up 700x700mm
down 750x750mm |
up 800x800mm
down 850x850mm |
up 950x950mm
down 1000x1000mm |
| Main cylinder diameter(mm) | 355 | 400 | 450 | 475 | 500 | 560 |
| Horse power(HP) | 10x2 | 10x2 | 10x2 | 15x2 | 15x2 | 15x2 |
| Electrical power(KW) | 22 | 34 | 34 | 43 | 48 | 72 |
| Gross weight(KG) | 90000 | 11500 | 13500 | 16500 | 19500 | 23500 |
| Machine size(L*W*H mm) | 3000x2360x2330 | 3300x2710x2530 | 3450x2630x2600 | 3600x2950x2600 | 3800x3300x2800 | 4200x3600x3300 |
Qingdao Dahua machinery Co., Ltd
Rubber machine, silicone material molding machine, injection machine, rubber machinery manufacturers / suppliers in China, providing high-precision rubber injection molding machine, rubber & silicone pressing machine, full automatic high speed molding press and so on.
Machine core parts:
Adopt foreign imported, such as Japan Mitsubishi PLC control system, Germany's Siemens control system, Taiwan PanelMaster HMI, Japan YUKEN oil pump, Taiwan heating pipes, Taiwan Victoria solenoid valves, Denmark TRAFAG pressure sensors, Japan NOK oil seal, Taiwan Tatung motors, Omron thermostat, Germany Busch vacuum pump, Fujitsu and other international brands accessories, stable quality, superior performance, low failure rate.
if you want more details, please contact us.
EMAIL: jackylee407@gmail.com
wechat: 0086 186 5323 7372
| Payment Terms: | TT / LC / DP / DA |
|---|---|
