Features:

1. USB wired barcode scanner to capture 1D, 2D code on labels, paper, mobile phone or computer.

2. High-efficiency recognization and high upload speed for improving your working efficiency.

3. With buzzer for reminding you that the scanning successfully or not.

4. Compatible with USB and UART interface.

5. Over 180 configurable options

6. Macro support replace a string in the bar code with another

7. Programmable preamble postamble and termination strings

8.Superior reading performance utilizing advanced decoding algorithms



PERFORMANCE PARAMETERS

Decoding  Ability:

   1D: EAN- 8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codebar,industrial 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,postal code ect.

   2D: PDF417,QR Code ,Data Matrix  ect.

Type of Illuminant: 617nm LED(Aimer), 6500K LEDs(Illumination)

Scan Angle: Roll:0-360°, Pitch:±65°or greater, Yaw:±60°or greater

Scanning angle Inclination angle: 34°, Elevation angle 26°

Print Contrast 30% minimum reflective difference

Resolution: 0.10mm (4mil)

Reading Distance :25 - 250mm

LED Indicator:Buzzer and bi-color light: Red-power, Blue-decoding Successfully

Interfaces: USB2.0 \ UART

Operating Temperature:-20 degrees to 55 degrees

Storage Temperature:-40 degrees to 65 degrees

Temperature Humidity:5% to 95% Relative humidity, Non-condensing

Light Levels:0-85000LUX

ELECTRICAL PARAMETERS

Operating Voltage :5V

Operating Current :120mA

You can dowload GM66 user manual from the following website:

https://www.dropbox.com/sh/buysgr2aeutuub3/AADsvupiGseFm-6IowMBWGCOa?dl=0

 For shipment list, please see the following photo:
