Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop

Model:011
Brand:HRBY
Origin:Made In China
Category:Construction & Decoration / Waterproof Materials
Label:bentonite waterstop , hydrophilic watersto , swellable waterstop
Price: US $0.45 / M
Min. Order:1000 M
Inquire Now Add to Basket

Member Information

Detail

Hongrui Boya (Tianjin) Trading Co.,Ltd.

Free MemberHe Bei - China
Live Chat:Last Online:24 Apr, 2019

Product Description

Contact person: Lisa Kang

Email: lisa@shuanglinrubber.com

Product & Usage

Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop



Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop is an absorbent strip used to seal and waterproof concrete joints. It is commonly made of natural sodium bentonite clay and synthetic rubber. Both the modified synthetic rubber and the bentonite expand in the joint when exposed to moisture. It is a new type of waterproof material, water stop, waterproof effect is more reliable than ordinary rubber. In contact with water the waterstop strip will swell approximately 150%-600 % of its original dry volume, the expansive clay mass will seal the cracks and small voids in the joint.

Contact us for details.

Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop

Why coose us

Contact us for details.
 Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop

Physical Properties

Hydrophilic Bentonite Waterstop

Hydrophilic Bentonite Waterstop

Index

Model

PN-220

PN-300

Color

black or red

black or red

Volume expansion rate %≧

220

300

Flow at high temperature (80℃×5h)

No flowing

No flowing

Low-temperature test (-20℃×5h)

No craking

No craking

Hydrophilic Rubber Waterstop

Hydrophilic Rubber Waterstop

Index

Model

PZ-250

PZ-400

Color

Red

Red

Hardness(Shore A)

42±10

45±10

Tensile strength, MPa≥

3.5

3

Elongation at break, %≥

450

350

Volume expansion rate%

250

400



Repeated water immersion test

Tensile strength MPa≥

3

2

Elongation at break %≥

350

250

Volume expansion rate %

250

300

Cold bending(-20º C× 2h)

No cracks

No cracks

Packing & Delivery

Packing Details:

10mm×20mm: 10m/roll, 80m/carton;
15mm ×20mm: 7m/roll, 49m/carton;
20mm×25 mm: 5m /roll, 30m/caron;
20mm×30 mm: 5m /roll, 25m/caron;
10mm x40mm or 30 mm × 50 mm: 3m or 4m or 5m/roll
For LCL: 45-63 cartons on one pallet.
For FCL: 1260 cartons in a 20 ft container.

Delivery Details:

Around seven days after receiving the payment.

Our Company

Hongrui Boya (belongs to Shuanglin Group) professionally supplys Road, bridge and building support, expansion joint, waterproof materials.
It has one factory, three companies for domestic and foreign markets. 50 workers, 8 enginnerings, and over 20years experience of manufacture.
Main products are Bridge bearings, bridge expansion joint, concrete waterstop products, rubber air bag, polysulfide sealant etc.
ISO certification, CE standard, AASHTO, and SGS test, with a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in infraconstruction and other industries.

Our Customers

Contact us for details.
Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop

Related Products

Rubber water stop

Widely used in underground installation, tunnel and cu ert, impounding reservoir, metro, and retaining dam and so on.

Tunnel Segment Gaskets

Used in shield method construction tunnel segment, connection passages, and seal and waterproof of prefabricated lining joint.

Polysulfide joint sealant

Used in movement and control joints, Structural floor joints, Airport runways and apron pavements, Swimming pool floors, ect.

FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 2-3 days if the goods are in stock. or it is 3-7 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=3000USD, 100% in advance. Payment>=3000USD, 30% T/T in advance ,balance before shippment or against the B/L copy.
If you have another question, pls feel free to contact us as below:


Product Image

Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop 1
Img 1
Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop 2
Img 2
Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop 3
Img 3
Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop 4
Img 4
Concrete Joints Rubber Hydrophilic Swellable Bentonite Waterstop 5
Img 5
